Checking the oil automatic
system
Check the oil level and the automatic oil
system before commencement of work.
• Switch on the chainsaw and hold it
above a bright background. The saw
must not touch the ground.
If an oil trace can be seen, the chainsaw
is working trouble-free.
If no oil trace can be seen clean
the oil passages or turn the chain-
saw to our Service-Center for re-
pair.
J
Clean the oil passages of the chain
bar (25), in order to guarantee a
trouble-free, automatic oiling of the
saw chain during operation.

Changing the saw bar

1. Switch the saw off and unplug it
F
from the mains.
2. Lay the saw on a flat surface.
3. Turn the fastening bolt (14)
anti-clockwise and loose the
chain adjustment ring
remove the sprocket chain wheel
covering (15).
4. Remove the saw bar (4) and
saw chain
guide bar (4), raise it to an angle
of approx. 45 degrees. This will
make it easier to take the saw
chain (5) off the sprocket
5. To fit the new bar, place the bar
(4) onto the bar bolt (21) with
the tensioning plate pointing out-
wards (22).
( 13)
A
( 5). To remove the
A
( G

Fitting the saw chain

1. Switch the saw off and unplug it
G
from the mains.
2. Spread the chain (5) out into a
loop with the cutting edges run-
ning clockwise .
3. Slide the saw chain (5) into the
bar guide groove. To mount the
guide bar (4), raise it to an angle
of approx. 45 degrees. This will
make it easier to replace the saw
chain (5) onto the sprocket (23).
It is normal that the saw chain
(5) is slack. Sagging in the chain
is normal.
4. Pre-tighten the chain (5) by
turning the tensioning plate (22)
clockwise.
5. Position the sprocket chain
wheel covering (15). First place
the tab (24) on the cover into the
corresponding notch on the plate
(15). Only lightly tighten the fas-
tening bolt (14), as you will still
have to tension the saw.
Refer to the start-up section on
how to tension the saw chain.

Sawing techniques

to

General

• You have better control when you saw
with the bottom side of the chain bar
(with pulling saw chain) and not to
with the top side of the chain bar (with
23). pushing saw chain).
• The saw chain must not contact either
the ground or another object during
sawing through or after sawing com-
pletion.
