PRESSURE REGULATOR SELECT ERGO
Operating instruction

12. Storage

12.1 Storage with gas cylinder

DANGER
Danger of breaking off the gas cylinder valve
Unsecured cylinders can fall over/fall down.
• Secure the gas cylinders from falling over/falling down.
• Store the pressure regulator clean and dry.
• Always store the gas cylinders with residual pressure (red display area pressure gauge) to
prevent humidity from entering the pressure regulator. Pressureless gas cylinders must
be stored in a dry place.
• Protect gas cylinders and the pressure regulator from sunlight, heat, UV radiation,
precipitation and other environmental influences as well as from contamination.
• Observe the maintenance intervals for stored pressure regulators.

12.2 Storage without gas cylinder

• Store the pressure regulator as long as possible in its original packaging.
• Store the pressure regulator clean and dry.
• Protect pressure regulator from sunlight, heat, UV radiation, precipitation and other
environmental influences as well as from contamination.
• Observe the maintenance intervals for stored pressure regulator.

13. Disposal

• Do not dispose the pressure regulator in the household waste.
• Return the pressure regulator to customer service or the manufacturer
for correct disposal.
• Dispose of the packaging in accordance with local waste regulations.

14. Technical data

Gases (see type plate)
Inlet connection
Gas cylinder pressure P1*
Flow outlet
Document: 0172.14.332 Index d 2021-03-25
oxygen 200bar, oxygen 300bar, medical air, carbon
dioxide
W30x2 acc. ISO5145
G3/4" acc. DIN477 No.9
G5/8" acc. BS341 No.3
W21,8x1/14" acc. DIN477 No.6
PIN-Index acc. DIN 407
up to 300bar (gas specific)
Type hose nipple acc. to DIN EN 13544-2
9/16" adapter with hose nozzle
Flow settings 12 flow rates from 0 to max. 35 l/min*
