PRESSURE REGULATOR SELECT ERGO
Operating instruction
3.

Device and function overview

Overview of operating elements and markings of the gas cylinder valves and a short
description of the function.

3.1 Product overview

K622-24X/34X
1
2
optional accessories
1 – inlet connection
2 – pressure gauge
3 – pressure relief valve (safety valve)
4 – flow outlet hose nipple
5 – handwheel
Document: 0172.14.332 Index d 2021-03-25
4
7
6
6 – inlet connection PIN INDEX (optional)
7 – pressure outlet (optional)
8 – flow outlet screw connection (optional)
9 – flow outlet screw adapter with hose nozzle
(optional)
3
7
8
9
5
