PRESSURE REGULATOR SELECT ERGO
Operating instruction

3.2 Markings

Document: 0172.14.332 Index d 2021-03-25
Type plate
Each pressure regulator bears a type plate with the following
information:
Type name:
Working pressure:
Gas type:
Type number:
Serial number:
Production date:
EC conformity:
Manufaturer: VTI
Iserlohner Landstr. 119
58706 Menden
Germany
Maintenance label
The inspection label indicates when the next
maintenance must be carried out.
The handwheel is marked with the flow steps in l/min.
The arrow on the housing shows the set flow steps.
Pressure outlets are marked with the inscription "5 bar".
Select Ergo
e.g.: 200 bar
e.g.: O2
e.g.: 622241
consecutive, six-digit
year/month
CE 0482
25
