B. Product Overview
Basic Operations and Front View
Built-in Webcam (5.0MP)
Built-in Microphone
Display with touch panel function
About LCD display:
This product uses a TFT LCD display. Note that some
pixels may always appear off (black) while some are
always on (orange, green, or blue). Depending on the
viewing angle, uneven color or uneven brightness may be
observed. Please note that these are natural characteristics
of TFT LCD and should not be regarded as defects.
Power button
LED indicator
OSD Menu / Exit
Arrow Button (Up/Right)
Arrow Button (Down/Left)
Input Signal Switch / OSD Menu Select
Back View
LEFT SIDE
LAN port (RJ-45)
HDMI-OUT jack
HDMI-IN jack
Headset jack
Microphone IN
SD Card Slot
MiniUSB port (OTG)
DC-in jack
RIGHT SIDE
USB Type-A x 4
USB Type-B
Please do not use AC adapters other than the one
supplied in this product package to prevent fire and
electric shock.
Please do not place objects on the AC adapter, or cover it
with anything. Overheating of the AC adapter may lead to a
fire.
LEFT SIDE
1
2
3
4
5
6
7
8
12
RIGHT SIDE
1
2
