Quick installation guide IB-HUB1418-i3
Installation
1.
•
Turn OFF the power to your computer and any other connected
peripheral devices.
•
Unplug the power cord from the back of the computer.
•
Remove your computer's cover.
•
Put the panel in one free 3.5" bay and fix it with the supplied screws.
•
Connect a free SATA power cable from the power supply to the port
on the hub.
•
Connect the supplied USB cable to the USB 20 pin connector of the
mainboard on one side and to the USB Type-A connector of the hub
on the other side. For the alignment on the mainboard, please refer to
the manual of the mainboard.
•
Replace the computer cover and reconnect the power cord.
2.
