Parts List for JDP-2800VS
Index No. Part No. Description Size Qty
1 ............... PM2800-001 ........... Strain Relief ....................................................... ................................... 2
2 ............... TS-1482051 ............ Hex Cap Screw .................................................. M6x25 ........................ 4
3 ............... PM2800-003 ........... Retaining Plate .................................................. ................................... 1
4 ............... TS-1490031 ............ Hex Cap Screw .................................................. M8x20 ........................ 4
5 ............... TS-1533052 ............ Pan Head Screw ................................................ M5x16 ........................ 2
6 ............... PM2800-007 ........... Cord Clamp ....................................................... ................................... 2
7 ............... TS-1534052 ............ Pan Head Screw ................................................ M6x16 ........................ 2
8 ............... JDP2800-008E ........ Lower Pulley Cover ............................................ ................................... 1
9 ............... TS-0680021 ............ Flat Washer ....................................................... 1/4 .............................. 4
10 ............. PM2800-011 ........... Strain Relief ....................................................... ................................... 1
11 ............. TS-1503041 ............ Socket Head Cap Screw .................................... M6x16 ........................ 1
12 ............. JDP2800-012E ........ Motor ............................................................... 1HP, 230V, 1Ph .......... 1
................. JDP2800-012AE ..... Motor ............................................................... 1.25HP, 400V, 3Ph ..... 1
13 ............. TS-1503031 ............ Socket Head Cap Screw .................................... M6x12 ........................ 1
14 ............. TS-0680021 ............ Flat Washer ....................................................... 1/4 .............................. 1
15 ............. PM2800-016 ........... Spring Cap ........................................................ ................................... 1
16 ............. PM2800-017 ........... Variable Speed Belt ........................................... 17x5x776 .................... 1
17 ............. PM2800-018 ........... Pulley ................................................................ ................................... 2
18 ............. PM2800-019 ........... Compression Spring .......................................... ................................... 2
19 ............. PM2800-020 ........... Shaft Sleeve ...................................................... ................................... 1
20 ............. PM2800-021 ........... Key .................................................................... 5x5x35 ........................ 2
21 ............. PM2800-022 ........... C-Ring ............................................................... A-30 ........................... 2
22 ............. TS-1533042 ............ Pan Head Screw ................................................ M5x12 ........................ 2
23 ............. PM2800L-02 ........... Guard ................................................................ ................................... 2
24 ............. PM2800L-03 ........... Laser Assembly ................................................. ................................... 2
25 ............. PM2800L-04 ........... Laser Module ..................................................... ................................... 2
26 ............. JDP2800-026E ........ Slotted Set Screw .............................................. M6x6 .......................... 3
27 ............. TS-1523011 ............ Set Screw .......................................................... M6x6 .......................... 2
28 ............. PM2800L-06 ........... Laser Housing ................................................... ................................... 2
29 ............. PM2800L-08 ........... Laser Plunger Housing ...................................... ................................... 2
30 ............. PM2800-023 ........... Set Bolt .............................................................. ................................... 2
31 ............. PM2800-024 ........... Center Pulley Assembly ..................................... ................................... 1
32 ............. PM2800-025 ........... C-Ring ............................................................... B-35 .......................... 1
33 ............. BB-6202ZZ.............. Ball Bearing ....................................................... 6202ZZ ....................... 2
34 ............. PM2800-027 ........... Collar ................................................................. ................................... 1
35 ............. PM2800-028 ........... Center Shaft ...................................................... ................................... 1
36 ............. PM2800-029 ........... Center Pulley ..................................................... ................................... 1
37 ............. PM2800-030 ........... Post ................................................................... ................................... 1
38 ............. TS-1524011 ............ Set Screw .......................................................... M8x8 .......................... 2
