Symbols:
 = after use,  = every week,  = every month
Activity
Check the motor ventilation for the collection of
dust and clean when necessary
Clean the brushes
Clean the pads and let them dry
Wipe down the machine with a damp cloth
Service intervals
TASKI machines are built to the highest quality standards. This is supported by
internationally recognised quality control procedures. Electrical and mechanical
parts are subject to wear or aging if used for long periods of time.
• In order to maintain operational reliability and availability for use, the service
must be carried out after 250 working hours or at least once a year.
Under rough or extreme working conditions and/or insufficient maintenance,
shorter periods are necessary.
Service centre
Should you contact us due to a malfunction or for placing an order, please
always state the type, description and the serial number of your machine.
You can find this information on the name plate of your machine, and the
address of your nearest TASKI partner can be found on the last page of this
manual.

Malfunctions

Malfunction Possible causes
Plug not plugged in to
the mains socket
Guide bar in upright
Machine does not
work position
Safety switch defect
The machine has
Machine cannot been overloaded,
be operated, but causing the
the switch is on overcurrent protection
to be tripped
Tool does not Motor runs but not
rotate the tool
Machine is
overloaded
Machine does not
reach rated
speed, motor
Insufficient voltage,
protection cuts in
power cord is too long
Machine runs Tool deformed or
uneasy damaged

Transport

• Remove the tool (refer to page 24).
• Pull the height adjustment lever and fold the
guide bar towards the front.
• Let go of the height adjustment lever, the guide
bar will locate into place and stay at that angle.
• To lift the machine, hold the machine between the wheels and the brush
cover while the second person holds onto the machine handle or on each
side at the brush cover.
  
page
23
24
24
24
Troubleshooting page
• Connect the power
supply cord to the
mains socket.
• Place the machine in
23
the working position
• Contact your service
partner 23
• Wait a while, try again
(the protection switch
will automatically
reset)
• Brush coupling, motor
axle or gearbox
possibly defective.
• Contact your service
partner
• Check if you are using
the correct working 23
technique
• Remove extention
• Check power supply
voltage
• Replace pad
Caution:
The machine must always be carried by at least two persons!
Ensure that the machine is firmly lashed down and secured in the transport
vehicle.

Disposal

When it has reached the end of its operational life, the machine and its
accessories must be disposed of according to the national regulations. Your
TASKI partner can support you with proper disposal upon notification.

Technical data

Machine
type
Brush width
Dimensions (L x W x H)
Machine weight
Additional weight
Total weight (including additional weight)
Rated voltage
Rated power
Frequency
Power supply cord length
Brush speed
Brush pressure
Assessed sound level LPA according to
ISO 11201
The assessed effective acceleration value according
to ISO 5349-1
Splash water protection
Protection class

Accessories

Article
8504390 Water tank
8504410 Driving disc 43cm
8504750 Scrubbing brush 43 cm
8504800 Scrubbing brush for washed concrete 43 cm
8504780 Scrubbing brush abrasive 43 cm
7518579 Extra weight 10 kg
HD
43LSHD
43 cm
46x48x107 cm
54 kg
10 kg
64 kg
220-240V ac
1100 W
50 Hz
15 m
150 min-1
0.4 N/cm2
<70 dB(A)
<2.5 m /s2
IPX4
I
HD
X
X
X
X
X
X
25
