Application Instructions - Out System Technisches Handbuch

APPLICATION
INSTRUCTIONS
PREPARING THE SUBSTRATE
OUT SYSTEM WET is the coating system
which allows to decorate damp indoor walls.
According to the surface to be coated, and
taking into consideration its nature, the
instructions contained in the following section
must be followed.
FOR RENDERED, PLASTERED, CEMENT,
PLASTERBOARD, THERMAL CAP SURFACES
Make sure the substrate is dry and cured. If
necessary, restore or fill in the substrate with
specific products. If mould is found, treat the
surfaces with specific products. Remove any
efflorescences and flaking old paints with a
brush or with water.
Completely remove any build-up of lime
based paints or tempera paints.
Remove the build-up of dust, smog and other
dirt by using a brush.
Treat holes and cracks with special fillers.
Seal fissures with suitable sealants.
According to the surfaces to be coated, the
application of a coat of water or solvent based
acrylic fixative is recommended.
According to the condition and colour of the
surface to be coated and if the background
of the selected OUT SYSTEM 02 fabric has a
light colour, the application of a coat of white
washable emulsion paint is recommended.
This procedure avoids the possible
staining of the substrate even after the
application of the OUT SYSTEM WET.
WOOD - PLASTIC - PVC SURFACES
Carefully clean the surface to be coated.
Slightly sand down the surface to remove
any flaking and to roughen the surfaces.
Remove any build-up of resin by using a
nitro thinner.
Fill any cracks or holes with a suitable filler.
Apply a coat of a special anchoring primer.
GLASS SURFACES
Carefully clean the surface and remove
any streaks caused by limescale with a
suitable acid based descaler.
Rinse well with a 2:1 ratio water
and ethyl alcohol solution and dry
it carefully with blotting paper.
TILED SURFACES
Clean the surface with a concentrated
mild detergent. Remove any traces of
limescale with a suitable acid based
descaler. Rinse with water and carefully
dry with blotting paper.
Apply a coat of anchoring primer suitable
for ceramic surfaces.
Thoroughly skim the surface with a
suitable non-shrinking fibre reinforced
skimming plaster.
After drying it well, apply a coat of water
based fixative, followed by a uniform coat of
washable emulsion paint.
Rigid armored polystyrene panels can be
used in alternative to mortar finishings.
This solution allows to drastically reduce
application time since there is no need to
wait for the double hand of mortar to dry
out. The panels occupy little space since
they are only 4 mm thick for a variable
length of either 50x100 cm or 50x200 cm.
Once applied, fill in the panel joints with
mortar and mesh.
APPLICATION AND CURING
Mix the specific adhesive OUT SYSTEM01 until
soft and uniform.
Smoothly apply the adhesive on the surface
with a short hair paint roller.
OUT SYSTEM01 delivers fast drying times; we
therefore recommend to apply the adhesive on
sections no larger than 5-7 m
The quantity of product used must be between
200 and 250 gr/m .
2
Before starting to apply the fabric OUT
SYSTEM02, check that it is perfectly lined up
and that the pattern is continuous.
Apply the technical fabric OUT SYSTEM02 by
pressing it with a plastic spatula to ensure
optimal adhesion.
By using a damp sponge, immediately remove
any surplus adhesive.
When the fabric is dry, trim its edges with
a cutter.
90°
at a time.
2
