pH/Redox/CL-A version
TOP VIEW
INPUT FLUX
+5Vdc GND
SIGN
on demand
INPUT
CL
1 2
NB: Connect the blue wire of chlorine probe to the terminal + and the brown wire to the terminal -.
Wire Connection:
1) Flow meter input connection
2) Chlorine measurement input
3) PH measurement input
4) Redox measurement input
5) Temperature probe input
6) REED contact input
7) Chlorine product level probe input
8) pH product level probe input
9) Flow (recirculation pump)
10) Chlorine relay (dry contact)
11) Alarm/Redox relay (dry contact)
Flow Meter input connection
0000137936
RS 485 TO EXTERNAL CONNECTOR
Description
PIN
3 3 4
1 T+ R+
INPUT CL
2 T- R-
3 GND
2 1
4 Not Used
-
+
INPUT INPUT
TEMP REED LEV
pH RX
- -
+ +
PROBE
3 4 5 6 7
(only if present)
(only if present)
Connect the Flow Meter as shown in the picture.
+5Vdc GND
Connect the +5V only if the sensor that you are connecting
SIGN
need the power supply voltage.
If the sensor doesn't need the power supply please let this pin
not connected.
15
16
pH
PUMP PUMP
LEV
CL pH
EXTERNAL
PUMP
8
rev. 6.1
14
CL
RELAY RELAY
Relay
INPUT Relay
FLOW CL ALARM/Rx
9 10
12) pH relay (dry contact)
13) 240 Vac power supply input
14) Chlorine pump power supply
15) pH pump power supply
16) Third external pump
RELAY
Relay
pH
L N
11 12 13
