Vagner Pool VA PRO SALT pH/ORP Anleitung Zur Einstellung Seite 7

pH/Redox version
INPUT CL
TOP VIEW
INPUT FLUX
+5Vdc GND
SIGN
on demand
INPUT
CL
1 2
NB: Connect the blue wire of chlorine probe to the terminal + and the brown wire to the terminal -.
Wire Connection:
1) Flow meter input connection
2) Chlorine measurement input
3) PH measurement input
4) Redox measurement input
5) Temperature probe input
6) REED contact input
7) Redox product level probe input
8) pH product level probe input
9) Flow (recirculation pump)
10) Redox relay (dry contact)
11) Alarm relay (dry contact)
0000137936
RS 485 TO EXTERNAL CONNECTOR
Description
PIN
3 4
3
1 T+ R+
2 T- R-
3 GND
2 1
4 Not Used
-
+
INPUT INPUT
TEMP REED LEV
pH RX
- -
+ +
PROBE Rx
3 4 5 6 7
(only if present)
(only if enabled)
(only if chlorine measure is enabled)
Main board
15 14
pH Rx
PUMP PUMP
LEV
pH
8
12) pH relay (dry contact)
13) 240 Vac power supply input
14) Redox pump power supply
15) pH pump power supply
rev. 6.1
RELAY
RELAY RELAY
INPUT Relay Relay
ALARM
FLOW Rx pH
9 10 11
L N
12 13
5
