Package Contents

- 2 -
Installation

IN-WALL INSTALLATION

Cabinet - mm
A
Model A B
DVF 1200 / Sierra 48" 1057 165
DVF 1500 / Sierra 60" 1331 165
DVF 1800 / Sierra 72" 1636 165
Firebox - mm
Model D E
DVF 1200 / Sierra 48" 1046 119
DVF 1500 / Sierra 60" 1318 119
DVF 1800 / Sierra 72" 1626 119
C
B
C
470
470
470
F
460
460
460
