Technical Specifications; Operation - aerauliqa QCmev Gebrauchsanleitung

to ensure adequate air intake, to ensure good combustion and proper equipment

operation.

• I nstall the product so that the impeller is not accessible from the air outlet side as
verified by contact with the Test Finger (test probe "B" of the norm EN61032) in
compliance with the current safety regulations.
• Make sure there is enough space around the unit for maintenance.
INTRODUCTION
QCmev is a whole house mechanical extract fan designed to be connected to self-adjusting valves.
Suitable for wall, ceiling, false-ceiling or floor installation, horizontally or vertically.
Version with integral humidistat available (QCmev 80 HY - QCmev 125 HY).

TECHNICAL SPECIFICATIONS

• Outer fan casing manufactured from powder coated galvanised sheet steel.
• Top cover made from strong ABS plastic.
• Internal self-extinguishing acoustic foam lining.
• EC external rotor motor for energy saving, mounted on ball bearings that guarantee a longer product life cycle
and suitable for cold climates.
• Forward curved centrifugal impeller to provide a smooth and silent airflow through the unit.
• Provided with multiple extract points:
QCmev80: air exhaust to outside through 1xØ125mm circular spigot + air extract from inside through
1xØ125mm + 4xØ80mm circular spigots.
QCmev125: air exhaust to outside through 1xØ125mm circular spigot + air extract from inside through
4xØ125mm circular spigots.
• IPX2 protection.
• Power supply 230V~ 50/60Hz.
OPERATION
Single speed operation
The unit runs at the speed set by turning the integral trimmer "V1" in the terminal box.
This is the default factory setting.
Wiring diagram: Fig. 5A - Dip switch configuration: 0000 for QCMEV 80/125 HY (Fig. 5F).
Wiring diagram: Fig. 5A - Dip switch configuration: 0001 for QCMEV 80/125 (Fig. 5F).
Two speed operation
The unit runs continuously at the speed set by turning the integral trimmer "V1" in the terminal box and can be
boosted at high speed, which is set by turning the integral trimmer "V2" in the terminal box. Boost is activated,
when needed, by means of a remote two-position switch (not supplied) or by means of remote sensors (SEN-
HY, SEN-CO2 or SEN-PIR), which are accessories on request.
Wiring diagram: Fig. 5B - Dip switch configuration: 1000 for QCMEV 80/125 HY (Fig. 5F).
Wiring diagram: Fig. 5B - Dip switch configuration: 1001 for QCMEV 80/125 (Fig. 5F).
Variable speed operation with CTRL-M remote manual controller (accessory on request)
The unit runs at the speed set by turning the knob of the CTRL-M remote manual control panel (accessory,
Fig. 6).
Wiring diagram: Fig. 5C - Dip switch configuration: 0100 for QCMEV 80/125 HY (Fig. 5F).
Wiring diagram: Fig. 5C - Dip switch configuration: 0101 for QCMEV 80/125 (Fig. 5F).
Variable speed operation through external domotic (BMS) system or ballast potentiometer
The unit runs at the speed set by turning the knob of an external 1-10V ballast potentiometer or set by an
external 1-10V signal from a domotic (BMS) system.
Wiring diagram: Fig. 5D - Dip switch configuration: 0110 for QCMEV 80/125 HY (Fig. 5F).
Wiring diagram: Fig. 5D - Dip switch configuration: 0111 for QCMEV 80/125 (Fig. 5F).
Three speed operation with SEL-3V speed selector (accessory on request)
6
