8 Konfiguration und Betrieb mit
TwinCAT 3
®
8.2.6 Digitaler I/O-Modus, Kanal B
Das Gerät unterstützt die Konfiguration von Kanal B (Pin 2) des IO-Link-Ports
über SDO 0x2383 im Input- oder Output-Modus.
SDO
Index Size
0x2383 8
Handbuch EtherCAT®
Version 1.2 05/2021
SDO content
Index Size
0x2383 : 1 1
0x2383: 2 1
0x2383: 3 1
0x2383: 4 1
0x2383: 5 1
0x2383: 6 1
0x2383: 7 1
8.2 Geräte-Parameter
Type Name
UINT8 Digital I/O Mode Port 1 Channel B
1 = Input
2 = Output
Others = reserved
Digital I/O Mode, Port 2 Channel B
UINT8
1 = Input
2 = Output
Others = reserved
UINT8 Digital I/O Mode, Port 3 Channel B
1 = Input
2 = Output
Others = reserved
UINT8 Digital I/O Mode, Port 4 Channel B
1 = Input
2 = Output
Others = reserved
Digital I/O Mode, Port 5 Channel B
UINT8
1 = Input
2 = Output
Others = reserved
UINT8 Digital I/O Mode, Port 6 Channel B
1 = Input
2 = Output
Others = reserved
UINT8 Digital I/O Mode, Port 7 Channel B
1 = Input
2 = Output
Others = reserved
