Inbetriebnahme
7.8.3
Modbus-, V1- oder WM550-Ausgang
1
E
2
1
CDI
i
1
3
F
2
4
HR
on
WP
POWER
SIM
35
Mögliche Positionen der "Modbus"- oder "V1"-Module (Beispiele); diese Module können je nach
Geräteausführung auch in den Slots B oder C sitzen.
Je nach Bestellcode kann das Gerät über eine oder zwei Modbus- oder V1-Kommunikations-
schnittstellen verfügen. Diese werden in folgenden Untermenüs konfiguriert:
Modbus
Setup → Erweitertes Setup → Kommunikation → Modbus X1-4 →Konfiguration
V1
• Setup → Erweitertes Setup → Kommunikation → V1 X1-4 → Konfiguration
• Setup → Erweitertes Setup → Kommunikation → V1 X1-4 → V1 Eingang Quellenauswahl
WM550
• Setup → Erweitertes Setup → Kommunikation → WM550 X1-4 → Konfiguration
• Setup → Erweitertes Setup → Kommunikation → WM550 X1-4 → Untermenü WM550
input selector
72
D
1
2
3
4
C
1
2
3
4
5
6
7
8
B
1
2
3
4
5
6
7
8
A
1
2
3
4
D
1 2 3 4
D1-4
A
1 2 3 4
A1-4
Proservo NMS80
A0031200
Endress+Hauser
