CAUTION:
• Secure the knob on the miter gauge carefully.
• Avoid creep of workpiece and gauge by firm
workholding arrangement, especially when
cutting at an angle.
• NEVER hold or grasp the intended "cut-off"
portion of the workpiece.
• Always adjust the distance between the end
of the miter gauge and the saw blade not to
exceed 15 mm.
Use of miter gauge
► Fig.40: 1. Miter gauge 2. Knob
Slide the miter gauge into the thick grooves in the table.
Loosen the knob on the gauge and align to desired
angle (0° to 60°). Bring stock flush up against fence and
slide table, secure it with the clamp on the miter gauge
and feed gently forward into the blade.
Auxiliary wood facing (miter gauge)
► Fig.41
To prevent a long board from wobbling, fit the miter
gauge with an auxiliary fence board. Fasten with bolts/
nuts after drilling holes, but fasteners must not protrude
from the face board.
Carrying tool
► Fig.42
Make sure that the tool is unplugged.
Carry the tool by holding the tool part shown in the
figure.
CAUTION:
• Always secure all moving portions before carry-
ing the tool.
• Always make sure that the blade guard is
installed in place before the carrying the tool.
MAINTENANCE
CAUTION:
• Always be sure that the tool is switched off and
unplugged before attempting to perform inspec-
tion or maintenance.
NOTICE:
• Never use gasoline, benzine, thinner, alcohol or
the like. Discoloration, deformation or cracks may
result.
Cleaning
Clean out sawdust and chips from time to time.
Carefully clean the blade guard and moving parts inside
the table saw.
Lubrication
To keep the table saw in tip-top running condition, and
to assure maximum service life, oil or grease the mov-
ing parts and rotating parts from time to time.
Lubrication places:
• Threaded shaft to elevate the blade
• Hinge to rotate the frame
• Elevation guide shafts on motor
• Gear to elevate the blade
Replacing carbon brushes
► Fig.43
Remove and check the carbon brushes regularly.
Replace when they wear down to 3 mm in length. Keep
the carbon brushes clean and free to slip in the holders.
Both carbon brushes should be replaced at the same
time. Use only identical carbon brushes.
► Fig.44: 1. Brush holder cap 2. Screwdriver
Use a screwdriver to remove the brush holder caps. To
replace the carbon brushes, remove the blade guard
and blade and then loosen the lock lever, tilt the saw
head and secure it at 45° bevel angle. Carefully lay the
tool on itself backward. Then loosen the brush holder
cap. Remove the worn carbon brushes, insert the new
ones and secure the brush holder caps.
To maintain product SAFETY and RELIABILITY, repairs,
any other maintenance or adjustment should be per-
formed by Makita Authorized Service Centers, always
using Makita replacement parts.
OPTIONAL
ACCESSORIES
CAUTION:
• These accessories or attachments are recom-
mended for use with your Makita tool specified
in this manual. The use of any other accessories
or attachments might present a risk of injury to
persons. Only use accessory or attachment for
its stated purpose.
If you need any assistance for more details regard-
ing these accessories, ask your local Makita Service
Center.
• Rip fence
• Miter gauge
• Wrench 24
• Hex wrench 5
• Joint ( for connecting to dust collector )
• Stand set
NOTE:
• Some items in the list may be included in the
tool package as standard accessories. They
may differ from country to country.
14 ENGLISH
