UNILITE HL-8R Kurzanleitung

FEATURES
• High quality 475 Lumen 6500K white SMD LEDs
• 2 x Side SMD LEDs for wide flood lighting
• 250 Lumen SMD LED for long distance spot beam
• Intelligent sensor mode for hands-free operation
• Super tough construction - IK07 shock resistant
• IP65 dust & water resistant
• 60° Rotational head
• Fully adjustable non-slip silicone headband
• Red-to-Green charging indicator
• Faster USB-C rechargeable (1m cable included)
• Quick 2 ½ hour charge time
BATTERY - 3.7v 1500mAh Li-polymer Rechargeable Battery
WEIGHT - 111g
DIMENSIONS - Headlight - H:47.5 x W:78.5 x D:46mm
OPERATION
RIGHT SWITCH = MAIN MODES
Switch sequence: SPOT BEAM > FLOOD LIGHT LOW > FLOOD LIGHT
MEDIUM > FLOOD LIGHT HIGH > OFF
MEMORY FUNCTION: If left in any mode for over 5 seconds, the next
press will turn off. Next time you turn ON, it will start at the Mode that
was last used.
LEFT SWITCH = SENSOR MODE
Press the left switch to activate SENSOR mode, a red light will appear to
confirm sensor mode is activated. Then wave your hand in front of the
head lamp to turn it ON or OFF (sensing distance less than10cm). Sensor
mode available in Floodlight High and Spot Beam modes. The Memory
Function will remember which mode was last used and the Sensor will
turn on these LEDs in High mode. Press SENSOR switch again to turn
SENSOR mode OFF.
ON/OFF
switch
www.unilite.co.uk
ANSI FL 1 Standard
SPOT BEAM
FLOODLIGHT - LOW
FLOODLIGHT - MID
FLOODLIGHT - HIGH
CHARGING
1.
2.
3.
4.
5.
6.
**Warranty void if not used with the specified chargers**
HEADBAND INSTALLATION
ADVICE & IMPORTANT INFORMATION!
Do not look directly at the LED. Do not operate in direct sunlight or extreme temperature conditions (below
-10⁰C or above 40⁰C).
LEDs will become warm/hot when switched on; do not touch and never place LEDs face down on any surface
– risk of fire!
Do not use the device if there is any visible damage to the housing, charge port or cable. Take care when
using a USB plug adaptor, check for any damage. DO NOT exceed 5V 1A charger output or damage may
occur to the battery.
The rechargeable battery will reach full performance after a few complete charging and discharging cycles.
To keep the rechargeable battery in optimum condition, it should be recharged every 3-6 months, especially
if it is not being used for a long period of time. Always fully charge batteries before storage.
Always protect batteries from heat, intense sunlight, fire, water and moisture – danger of explosion!
If a battery is damaged, fluids can leak out. AVOID contact as this can lead to skin irritation and/or burns. If
skin contact occurs, rinse thoroughly with water. If irritation persists, seek medical advice. Seek immediate
medical assistance if lithium battery fluid comes into contact with the eyes.
SENSOR
Children under 12 years of age should only use the product under adult supervision.
switch
Do not open, disassemble or attempt to modify the product; this will void the warranty and can be dangerous.
Improper use or modification is not covered under the warranty.
Take care not to let the lenses come into contact with hard/sharp objects, damage/scratches to the lenses
will affect light output.
This product is water resistant to IPX5 – DO NOT SUBMERGE. If the product has been subjected to excessive
moisture/water the warranty may be void.
This product has a 1 year standard warranty (or extended to 2 years once registered online at WWW.UNILITE.
CO.UK) against manufacturing faults and defects. It does not cover normal wear and tear, modifications,
accidental damage or poor maintenance. Unilite warranties do not cover battery leaks or the use of incorrect
chargers and cables that can damage batteries.
Do not dispose of this device in normal household waste. It must be disposed of via an authorised electrical
appliance disposal centre or at your local waste disposal unit.
Please re-use or recycle packaging where possible.
Keep these instructions for future reference or for subsequent possessors.
Only use a USB-C 5V cable (max 1A).
Lift the charging port cover on the bottom of the headlight.
Plug the USB-C end of the cable into the charge port.
Plug the USB end of the cable into a USB charging port (do not
exceed 5V 1A charging input or damage may occur).
Red LED indicates charging, green LED shows fully charged.
Charge Time: 2 ½ hrs
Charging Port
Detach headband
from the end
buckle
Feed the end buckle through these holes in the
back plate of the headtorch, then re-attach the
HL-8R
250
6 H
90 M
Lumens
30
6 M 35 H
Lumens
250
16 M 8 H
Lumens
475
25 M 4 H
Lumens
Red
Charging
Green Fully Charged
headband back onto the buckle.
