UNILITE HT-650R Kurzanleitung

FEATURES
• High quality 650 lumen white COB LED, 6500K
• Circular COB LED for wide flood lighting
• Additional 450 lumen Cree LED spot beam, 6500K
• Dual Power - rechargeable or 3 x AAA batteries
• Adjustable non-slip silicone lined headband
• 60° Rotational head
• IP65 dust & water resistant
• IK07 shock proof - 2m drop resistant
• Rechargeable 3.8v Li-Po battery included
• Red-to-Green charging indicator on battery
• Quick 3½ hour USB-C charge time - 1m cable included
BATTERY - 3.8v 1100mAh Li-polymer Rechargeable Battery
or 3 x AAA Alkaline Batteries (not included)
WEIGHT - 89g
DIMENSIONS - Headtorch - H:46.3 x W:68.7 x D:40mm
ADVICE & IMPORTANT INFORMATION!
Do not look directly at LEDs. Do not operate in direct sunlight or extreme temperature
conditions (below -10°C or above 40°C).
LEDs will become warm/hot when switched on; do not touch and never place LEDs
face down on any surface – risk of fire!
Do not use the device if there is any visible damage to the housing, battery, charge
port or cable. Take care when using a USB plug adaptor, check for any damage. DO
NOT exceed 5V 1A charging input or damage may occur to the rechargeable battery.
Only use Unilite's rechargeable battery, otherwise the manufacturer's warranty will
be void. The rechargeable battery will reach full performance after a few complete
charging and discharging cycles. To keep the rechargeable battery in optimum
condition, it should be recharged every 3-6 months, especially if it is not being used
for a long period of time. Always fully charge batteries before storage and remember
to remove the rechargeable battery from the headtorch before storage to avoid
battery depletion.
Always use high-quality alkaline 1.5v AAA batteries. Disposable battery life is affected
by different battery brands, different ambient temperatures and different lighting
modes. If not using the headtorch for 3 weeks or more be sure to remove the
disposable batteries to avoid battery leakage (not covered under warranty).
Always protect batteries from heat, intense sunlight, fire, water and moisture – danger
of explosion!
If a battery is damaged, fluids can leak out. AVOID contact as this can lead to skin
irritation and/or burns. If skin contact occurs, rinse thoroughly with water. If irritation
persists, seek medical advice. Seek immediate medical assistance if battery fluid
comes into contact with the eyes.
Children under 12 years of age should only use the product under adult supervision.
Do not disassemble or attempt to modify the product; this will void the warranty and
can be dangerous. Improper use or modification is not covered under the warranty.
Take care not to let lenses come into contact with hard/sharp objects, damage/
scratches to the lenses will affect light output.
This product is water resistant to IPX5 – DO NOT SUBMERGE. If the product has been
affected by damp, remove the batteries and leave the unit open and allow to dry
out completely before using. If the batteries are installed and the headlight does
not work, try checking for the following: (1) Press the switch button several times. (2)
Check that the batteries are inserted the correct way around according to polarity
markings. (3) Check there is no debris on the contacts that might affect the battery
connection. (4) Check there is no water or dampness in the light, if so, allow it to fully
dry out and try again. If the product has been subjected to excessive moisture/water
the warranty may be void.
This product has a 1 year standard warranty (or extended 2 years once registered
online at WWW.UNILITE.CO.UK/WARRANTY) against manufacturing faults and
defects. It does not cover normal wear and tear, modifications, accidental damage or
poor maintenance. Unilite warranties do not cover battery leaks or the use of incorrect
chargers and cables that can damage rechargeable batteries.
Do not dispose of this device in normal household waste. It must be disposed of via
an authorised electrical appliance disposal centre or at your local waste disposal unit.
Please re-use or recycle packaging where possible.
Keep these instructions for future reference or for subsequent possessors.
www.unilite.co.uk
ANSI FL 1 Standard
SPOT BEAM
FLOODLIGHT - HIGH
FLOODLIGHT - MID
FLOODLIGHT - LOW
OPERATION
Switch Sequence: SPOT BEAM >
FLOOD LIGHT HIGH > FLOOD
LIGHT MEDIUM > FLOOD LIGHT
LOW > OFF
MEMORY FUNCTION:- If left ON in
any mode for 5 seconds or more,
the next press will turn OFF. Next
press ON will return to that last
mode used.
BATTERY INSTALLATION
1. Open the headtorch by gently lifting the lip on the top of the
headtorch.
2. Insert either the Unilite Li-Po battery or insert 3 x high quality AAA
alkaline batteries making sure you take note of the polarity marks
to insert the correct way.
3. Then close the headtorch until the lip on the top clicks shut.
CHARGING THE RECHARGEABLE BATTERY
1. Only use a 5V 1A USB-C cable (max 1A).
2. Remove the battery from the headtorch.
3. Plug the USB-C end of the cable into the charge port on the front
of the battery.
4. Plug the USB-A end of the cable into a USB charging port (do not
exceed 5V 1A charging input or damage may occur).
5. Red LED indicates charging, Green LED indicates fully charged.
6. Charge Time: 3½ hours
*Warranty void if not used with the specified cable & max charge input*
Art.No: 4311AU/BA TTERY-HT650R
Rechargeable Li-Po Battery
Input: 5V / 1A USB-C
3.8V / 4.18Wh
HT-650R
3 X AAA
BATTERIES
450
3 H
84 M
Lumens
650
2 H
34 M
Lumens
350
4 H
18 M
Lumens
40
30 H
7 M
Lumens
ON/OFF
switch
AAA
OR
Art.No: 4311AU/ BATTERY-HT650R
Rechargeable Li-Po Battery
AAA
Input: 5V / 1A USB-C
AAA
3.8V / 4.18W h
Li-Polymer Battery 3 x 1.5v AAA Alkaline
(3.8v 1100mAh) Batteries
USB-C
Red
Charging
Green Fully Charged
LITHIUM
BATTERY
2 H
2 H
4 H
18 H
