UNILITE HT-650R Bedienungsanleitung

PRODUCT FEATURES
•
High quality 650 lumen white COB LED, 6500k
•
Circular COB LED for wide flood lighting
•
Additional 450 lumen Cree LED spot beam, 6500k
•
Dual Power - rechargeable or 3 x AAA batteries
•
Adjustable non-slip silicone lined headband
•
60° Rotational head
• IP65 dust & water resistant
• IK07 shock proof - 2m drop resistant
• Rechargeable 3.8V Li-Po battery included
• Red-to-Green charging indicator on battery
•
Quick 3 hour USB-C charge time - 1m cable included
1/2
BATTERY - 3.8V 1100mAh Li-polymer Rechargeable Battery
or 3 x AAA Alkaline Batteries (not included)
WEIGHT - 89g
DIMENSIONS - Headtorch - H: 46.3 x W: 68.7 x D: 40mm
ADVICE & IMPORTANT INFORMATION!
ƒ Do not look directly at LEDs. Do not operate in direct sunlight or extreme temperature
conditions (below -10˚C or above 40˚C).
ƒ LEDs will become warm/hot when switched on; do not touch and never place LEDs face
down on any surface – risk of fire!
ƒ Do not use the device if there is any visible damage to the housing, battery, charge port or
cable. Take care when using a USB plug adaptor, check for any damage. DO NOT exceed
5V 1A charging input or damage may occur to the rechargeable battery.
ƒ Only use Unilite's rechargeable battery, otherwise the manufacturer's warranty will be
void. The rechargeable battery will reach full performance after a few complete charging
and discharging cycles. To keep the rechargeable battery in optimum condition, it should
be recharged every 3-6 months, especially if it is not being used for a long period of time.
Always fully charge batteries before storage and remember to remove the rechargeable
battery from the headtorch before storage to avoid battery depletion.
ƒ Always use high-quality alkaline 1.5v AAA batteries. Disposable battery life is affected by
different battery brands, different ambient temperatures and different lighting modes. If
not using the headtorch for 3 weeks or more be sure to remove the disposable batteries
to avoid battery leakage (not covered under warranty).
ƒ Always protect batteries from heat, intense sunlight, fire, water and moisture – danger of
explosion!
ƒ If a battery is damaged, fluids can leak out. AVOID contact as this can lead to skin irritation
and/or burns. If skin contact occurs, rinse thoroughly with water. If irritation persists, seek
medical advice. Seek immediate medical assistance if battery fluid comes into contact
with the eyes.
ƒ Children under 12 years of age should only use the product under adult supervision.
ƒ Do not disassemble or attempt to modify the product; this will void the warranty and can
be dangerous. Improper use or modification is not covered under the warranty.
ƒ Take care not to let lenses come into contact with hard/sharp objects, damage/scratches
to the lenses will affect light output.
ƒ This product is water resistant to IPX5 – DO NOT SUBMERGE. If the product has been
affected by damp, remove the batteries and leave the unit open and allow to dry out
completely before using. If the batteries are installed and the headlight does not work,
try checking for the following: (1) Press the switch button several times. (2) Check that the
batteries are inserted the correct way around according to polarity markings. (3) Check
there is no debris on the contacts that might affect the battery connection. (4) Check
there is no water or dampness in the light, if so, allow it to fully dry out and try again. If
the product has been subjected to excessive moisture/water the warranty may be void.
ƒ This product has a 2 year standard warranty against manufacturing faults or defects. It does
not cover normal wear and tear, modifications, accidental damage or poor maintenance.
Unilite warranties do not cover disposable battery leaks or the use of incorrect batteries,
chargers, cables or power leads that can cause damage.
ƒ Do not dispose of this device in normal household waste. It must be disposed of via an
authorised electrical appliance disposal centre or at your local waste disposal unit.
ƒ Please re-use or recycle packaging where possible.
ƒ Keep these instructions for future reference or for subsequent possessors.
| EU Responsible Contact:
Aspen Pumps France, 353 Allee des Vergers, 76360 Barentin
Tel: +33 (0) 1 78 95 88 82 Email: ventes@aspenpumps.com
English
ANSI FL1 Standard
SPOT BEAM
FLOODLIGHT -
HIGH
FLOODLIGHT -
MEDIUM
FLOODLIGHT -
LOW
OPERATING INSTRUCTIONS
Switch Sequence: SPOT BEAM >
FLOOD LIGHT HIGH > FLOOD LIGHT
MEDIUM > FLOOD LIGHT LOW > OFF
MEMORY FUNCTION:- If left ON in any
mode for 5 seconds or more, the next
press will turn OFF. Next press ON will
return to that last mode used.
BATTERY INSTALLATION
1.
2.
3.
NOTE: When the battery level goes below 10% the headtorch will flash
3 times to alert the user.
RECHARGING
1.
2.
3.
4.
5.
6.
*Warranty void if not used with the specified cable & max charge input*
www.unilite.co.uk
450
Lumen
650
Lumen
350
Lumen
40
Lumen
Open the headtorch by gently lifting the lip on the top of the
headtorch.
Insert either the Unilite Li-Po battery or insert 3 x high quality AAA
alkaline batteries making sure you take note of the polarity marks
to insert the correct way.
Then close the headtorch until the lip on the top clicks shut.
Art.No: 4311AU/ BATTERY-HT650R
Rechargeable Li-Po Battery
Input: 5V / 1A USB-C
3.8V / 4.18W h
Li-Polymer Battery
Li-Polymer Battery
(3.8v 1100mAh)
(3.8V 1100mAh)
Only use a 5V 1A USB-C cable (max 1A).
Remove the battery from the headtorch.
Plug the USB-C end of the cable into the charge port on the front
of the battery.
Plug the USB-A end of the cable into a USB charging port (do not
exceed 5V 1A charging input or damage may occur).
Red LED indicates charging, Green LED indicates fully charged.
Charge Time: 3 hours
1/2
USB-C
USB-C
Art.No: 4311AU/BA TTERY-HT650R
Rechargeable Li-Po Battery
Input: 5V / 1A USB-C
3.8V / 4.18Wh
Tel: 01527 584344
HT-650R
3 X AAA LITHIUM
BATTERIES BATTERY
84M 3H 2H
34M 2H 2H
18M 4H 4H
7M 30H 18H
On/Off
Switch
AAA
OR
AAA
AAA
3 x 1.5v AAA Alkaline
3 x 1.5V AAA Alkaline
Batteries
Batteries
Red Charging
Charging
Green Fully Charged
Fully Charged
UNILITE
The LAB, Winyates Way, Redditch B98 9FG
Email: support@unilite.co.uk
|
