UNILITE HX800R Bedienungsanleitung

HX800R
FEATURES
• High quality 800 lumen 7W white COB LED, 6500K
• Additional 300 lumen 3W SMD LED spot beam, 6500K
• Ultra tough nylon-polymer construction
• 180° rotating stand with super strong magnetic base
• IP65 dust & water resistant
• IK07 shock proof - 2m drop resistant
• Operating temperature -20°C to +50°C
• High power 2600mAh lithium battery
• Battery level and charging indicator lights
• USB type-C rechargeable - 1m cable included
BATTERY - 3.7v 2600mAh Li-ion Rechargeable Battery
WEIGHT - 210g
DIMENSIONS - 93.5 x 80 x 35.5mm
OPERATION
REAR SWITCH Sequence:- Spot Beam > Floodlight Low > Floodlight Medium
> Floodlight High > Off
MEMORY FUNCTION:- If left ON in any mode for 5 seconds or more, the next
press will turn OFF. Next press ON will return to that last mode used.
SMD LED
COB LED
Super Strong Magnet
ADVICE & IMPORTANT INFORMATION!
Do not look directly at the LED. Do not operate in direct sunlight or extreme temperature conditions (below -10⁰C or above 40⁰C). The LED will become hot when switched on; do not touch
and do not place face down on any surface – risk of fire! Do not use the device if there is any visible damage to the housing, plug or cable. Children under 12 years of age should only use the
product under adult supervision.
Do not open, disassemble or attempt to modify the product; this will void the warranty and can be dangerous. Improper use or modification is not covered under the warranty.
Ensure the lens does come into contact with hard/sharp objects; damage to the lens may affect light output.
If the product has been subjected to excessive moisture/water the warranty may be void.
To maintain the rechargeable battery, distributors should recharge the battery every 6 months and users should recharge every 3 months if not using for an extended period. Fully charge
the product before storage. The rechargeable battery will reach optimum performance after several complete charging and discharging cycles.
Super Robust
Protect the battery from heat, intense sunlight, fire, water and moisture – danger of explosion!
Nylon Polymer
If the battery is damaged, fluids can leak out. AVOID contact as this can lead to skin irritation and/or burns. If skin contact happens, rinse thoroughly with water. If irritation persists, seek
medical advice. Also seek immediate medical assistance if battery fluid comes into contact with the eyes.
Do not dispose of this device in normal household waste. It must be disposed of via an authorised disposal centre or at your local waste disposal unit.
Please recycle packaging where possible. Keep these instructions for future reference or for subsequent possessors.
Unilite Limited | The LAB | Moons Moat Drive
T • F •
+44 (0)1527 584 344
Super Robust
Nylon Polymer & Rubber
Stand
Rotates 180°
Battery Level &
Charge Indicators
ON/OFF
Switch
| Off Winyates Way
E •
+44 (0)1527 584 345 sales@unilite.co.uk
SMD LED
ANSI FL 1 Standard
COB LED
FLOOD LIGHT - HIGH
FLOOD LIGHT - MID
FLOOD LIGHT - LOW
SPOT BEAM
CHARGING
1. Only use a USB-type-C 5v cable.
2. Switch product off before charging (do not switch on
whilst charging).
3. Lift the charge port cover on the back of the light.
4. Plug the USB-C end of the cable into the charge port.
5. Plug the USB end of the cable into the UK-USB 1A adaptor
Super Strong Magnet
(included) or any other USB charging port (max 1A).
6. 3 x Green LEDs will flash to indicate charging. Once fully
charged all 3 LEDs will be lit up constantly.
7. Charge Time: 4 hours
**Warranty void if not used with the specified charger**
Super Robust
Nylon Polymer
Stand
Rotates 180°
| Redditch | Worcestershire | B98 9FG
W •
www.unilite.co.uk
Super Robust
Nylon Polymer & Rubber
800
38 M
Lumens
450
25 M
Lumens
150
12 M
Lumens
300
26 M
Lumens
Stand
Rotates 180°
Battery Level &
Charge Indicators
ON/OFF
Switch
Charge
Super Strong Magnet
| UK
2½ H
5 H
12 H
4 H
Port
