UNILITE HL-4R Kurzanleitung

FEATURES
• 275 Lumen white Cree® LED
• 2 x 5mm red LEDs for night vision - on and flashing
• USB rechargeable high power lithium battery
• Red-to-Green charging indicator
• IPX5 water resistant
• 45° rotational head
• Fully adjustable non-slip silicone headband
• Easy push micro switch
• 3M™ VHB™ adhesive helmet mount included
• Comes with a handy drawstring storage/carry pouch
BATTERY - 3.7v 1800 mAh lithium-polymer rechargeable battery
WEIGHT - 78g (including battery)
DIMENSIONS - 63 x 40 x 42 mm
ADVICE & IMPORTANT INFORMATION!
Do not look directly at the LED. Do not operate in direct sunlight or extreme temperature conditions (below
-10⁰C or above 40⁰C). LEDs will become warm/hot when switched on; do not touch and never place LEDs face
down on any surface – risk of fire!
Do not use the device if there is any visible damage to the housing, charge port or cable. Take care when using
a USB plug adaptor, check for any damage. DO NOT exceed 5V 1A output or damage may occur to the battery.
The rechargeable battery will reach full performance after a few complete charging and discharging cycles.
To keep the rechargeable battery in optimum condition, it should be recharged every 3-6 months, especially if
it is not being used for a long period of time. Always fully charge batteries before storage.
Always protect batteries from heat, intense sunlight, fire, water and moisture – danger of explosion!
If a battery is damaged, fluids can leak out. AVOID contact as this can lead to skin irritation and/or burns. If skin
contact occurs, rinse thoroughly with water. If irritation persists, seek medical advice.
Seek immediate medical assistance if lithium battery fluid comes into contact with the eyes.
Children under 12 years of age should only use the product under adult supervision.
Do not open, disassemble or attempt to modify the product; this will void the warranty and can be dangerous.
Improper use or modification is not covered under the warranty.
Take care not to let the lens come into contact with hard/sharp objects, damage/scratches to lenses will affect
light output.
This product is water resistant to IPX5 – DO NOT SUBMERGE. If the product has been subjected to excessive
moisture/water the warranty may be void.
This product has a 2 year warranty against manufacturing faults and defects. It does not cover normal wear
and tear, modifications, accidental damage or poor maintenance. Unilite warranties do not cover battery leaks
or the use of incorrect chargers and cables that can damage the battery.
Do not dispose of this device in normal household waste. It must be disposed of via an authorised electrical
appliance disposal centre or at your local waste disposal unit.
Please re-use or recycle packaging where possible.
Keep these instructions for future reference or for subsequent possessors.
WWW.UNILITE.CO.UK
ANSI FL 1 Standard
WHITE - HIGH
WHITE - MED
WHITE - LOW
RED - HIGH
RED - 2Hz FLASH
RED - SOS
OPERATION
Press Press
WHITE
HIGH
Press Press
WHITE
MEDIUM
Press Press
WHITE
LOW
WHEN 'ON' IN EITHER WHITE OR RED MODE, PRESS AND HOLD TO WHEN 'ON' IN EITHER WHITE OR RED MODE, PRESS AND HOLD TO
WHEN 'ON' IN EITHER WHITE OR RED MODE, PRESS
SWITCH TO THE THE OTHER MODE SWITCH TO THE THE OTHER MODE
AND HOLD TO SWITCH TO THE OTHER MODE
CHARGING
1. Only use a USB-type-C 5V cable (1m Cable included)
2. Lift the charging port cover on the side of the headlight.
3. Plug the USB-C end of the cable into the charge port.
4. Plug the USB end of the cable into a USB charging port.
(do not exceed 5V 1A output or damage may occur)
5. Red LED flashing indicates charging, green LED shows fully charged.
6. Charge Time: 2 ½ hrs
**Warranty void if not used with the specified chargers**
Battery &
Charging Indicator
BATTERY INDICATOR
Red = Less than 30% remaning
Green = upto 70% battery
275
95 M
Lumens
75
46 M
Lumens
9
15 M
Lumens
4
--
Lumens
4
--
Lumens
4
--
Lumens
Press Press
WHITE
HIGH
Press Press
WHITE
MEDIUM
Press Press
WHITE
LOW
[If left in any mode for over 3 seconds,
[If left in any mode for over 3 seconds, the next press will turn off] [If left in any mode for over 3 seconds, the next press will t
the next press will turn off]
CHARGING INDICATOR
Red Flash = Charging
Green = Fully Charged
HL-4R
6½ H
13 H
77 H
60 H
170 H
90 H
RED RED
HIGH HIGH
RED RED
2Hz FLASH 2Hz FLASH
RED RED
SOS SOS
