9. Technical Information

EMS-3 plotter specifications
Type of plotter:
Maximum plotting area:
Plotting speed with pen:
Plotter pen:
Ports:
Control language:
Buffer:
Drive:
Pen station:
Addressable resolution:
Repeat accuracy:
Repeat accuracy after pen change: .05 mm with optimum pen
Power supply:
Power supply input voltage:
Power supply input current:
Power supply output voltage:
Power supply output current:
Environmental conditions:
Safety certificate:
Interference safety compliance:
Dimensions:
Weight:
Flatbed plotter
422 mm x 305 mm
up to 40 mm/s
Special plotter pens with HP fixing
USB Level 2.0
Based on HP-GL 7475A
16 MB
Two-phase step motor
Max. 4 plotter pens with double seal
.01 mm
.05 mm
Via separate power supply with exchangeable
mains power connection
100-240V AC / 50-60Hz
.7 A max.
24 V DC
1.25 A max.
In use: 10°C-35°C
35%-75% relative humidity
Storage: -10°C-50°C
10%-90% relative humidity
EN 60950-1
EN 55022 B
EN 61000-4-2, -4-3, -4-4, -4-5, -4-6
690 mm x 480 mm x 155 mm
8.3 kg
