5. Operation

Once you have installed the EMS-3 and connected the power supply and data cable,
you can switch the plotter on.
Important:
Before switching the device on please ensure that there are no objects on the
writing/plotting area which might prevent the writing arm from moving freely.
All settings and commands are entered using the control panel.
Control Panel
Switch device
ON/OFF
Manual movement
in X and Y directions,
pen up/pen down
Internal buffer
loaded
Plotter Stop mode
Engraving mode
Penstation open
Plotter out of
order, PCB failure
Plotter ON/OFF
Open and close
pen station to
insert/remove
plotter pen
Delete data
downloaded from PC
Pause or stop
plotter activity
7
