8 .8 Enabling menu access
26. Press to access the menu.
27. "Code, 0000" is displayed. The first digit is highlighted.
28. Enter the code by changing the highlighted code digits
with . Confirm the entry with
highlighted. Change the other highlighted digits in the
same way, by pressing
29. After the last confirmation with
option in the menu is displayed. Access to the menu is
re-enabled. Pressing
menu options to configure other settings. Pressing
shows the start display.
8 .9 . Reset
The "Reset" and "Factory setting" functions are located under
the "Reset" menu option. The "Reset" function activates and
deactivates and/or restarts the torque wrench with built-in angle
gauge. When "Reset" is selected, the system is brought to a
defined starting condition. This may be necessary if the wrench
no longer functions properly and does not respond to the normal
inputs. The "Factory settings" function returns the torque wrench
with built-in angle gauge to its status upon dispatch from the
factory and activates, reactivates and/or restarts it, just as the
"Reset" function does.
NOTE! Warning, all self-programmed settings, param-
eters sets and workflows will be deleted

Design and function
. The next digit is
and confirming with .
, the "Mode" menu
enables you to select other
8 .10 . Application / operation
torque wrench with built-in angle gauge
The torque wrench with built-in angle gauge must only be oper-
ated with the handle at right angles to the screw joint. The hand
force deployed must be applied uniformly onto the centre of the
handle (ring marking).
In order to avoid measurement errors when measuring the rotation
angle, do not allow the screwed workpiece or its support to turn,
move or sway during operation.
You can also activate the dimmed display to reduce the power
consumption.
After approx. 30 seconds the display is dimmed slightly.
8 .11 PC connection
The torque wrench with built-in angle gauge is ready to be con-
nected to the optionally available Smart Tool software. The sub-
sequent procedures for establishing a connection, reading saved
data and for programming the wrench with the software are part
of the operating instructions for the SmartTAC Tool software.
of the
