Neopost AS-970C Kurzanleitung

1 step
st
Unpack your Printer:
- Remove the printer and accessories from
the packaging.
- Store the packing material in a safe place.
- Set the printer onto a level, stable surface.
Use a carpenter's level to make any
adjustments to the work table where the
printer will be operating.
Level is very important to the proper
operation of the printer, and the electronics
of the unit will check for it once powered
up. Do not move the printer while the
power is on.
Quick start Guide for the Printer AS-970C
2 step
nd
WARNING!
DO NOT PLUG-IN OR POWER UP THE PRINTER
BEFORE REMOVING PACKING MATERIALS!
1. CARDBOARD "SHIPPING INSERT"
2. HEAD MEDIA GUIDE SHIPPING TAPE.
DAMAGE TO PRINTER MAY RESULT!
"Shipping Insert" secures the Service Station and
Tape holds the Head Media Guide during printer
transport. Please remove Insert [1-4]
[5] as shown below (Save for future reference):
1 2 Release latches, lift
up with both hands
3 4
Tabs Remove
5a 5b
Remove Remove
3 step
rd
Install Media Guides:
Locate the side guides and
-
rear media support guide in the
accessory box (wrapped in foam).
- Install the side guides to the hopper
brackets where the mounting
screws are taped in place. The
rear media support guide mounts
with the large rubber thumbscrew
on the back plate, and the media
and Tape support wedge attaches to it with
a thumbscrew.
- When complete, your machine
should look like this:
Head
Media
Guide
4 step
th
Connect Power to the
Printer:
- Make sure that the main power switch
(item 1 in the image below) is in the OFF
position.
- Plug the AC power cord into the receptacle
on the printer, located below the main
power switch.
- Plug the other end of the AC power cord
into a 220-230V/ 50 Hz grounded outlet
with a high quality surge protector.
DO NOT
turn the
power
switch (1)
on at that
time!
29/01/2021 - A0001258/F
1/14
