Siemens SIMOCODE pro Betriebsanleitung Seite 3

Order No.
3UF7000-1AB00-0 24 V DC
3UF7000-1AU00-0 110 V ... 240 V AC / DC
3UF7010-1AB00-0 24 V DC
3UF7010-1AU00-0 110 V ... 240 V AC / DC
Technical Assistance: Telephone: +49 (0) 911-895-5900 (8°° - 17°° CET)
E-mail:
Internet:
Technical Support: Telephone: +49 (0) 180 50 50 222
Technische Änderungen vorbehalten. Zum späteren Gebrauch aufbewahren!
Subject to change without prior notice. Store for use at a later date.
© Siemens AG 2005
A1/A2 T1/T2
A1 (+) / A2 (–)
A1 / A2
A1 (+) / A2 (–)
P
A1 / A2
technical-assistance@siemens.com
www.siemens.de/lowvoltage/technical-assistance
PZ2/ Ø 5 ... 6 mm
10
10
3UF7930-0AA00-0 (0.025 m)
3UF7931-0AA00-0 (0.1 m)
3UF7932-0AA00-0 (0.5 m)
3UF7933-0AA00-0 (2 m)
Deutsch: 3UF7970-0AA01-0
English: 3UF7970-0AA00-0
Français: 3UF7970-0AA02-0
Fax: +49 (0) 911-895-5907
www.siemens.com/lowvoltage/manuals
Bestell-Nr./Order No.: 3ZX1012-0UF70-1AA1
Printed in the Federal Republic of Germany
TORQUE: 7 ... 10.3 LB.IN
0,8 ... 1,2 Nm
2 x 0,5 ... 2,5 mm²/1 x 0,5 ... 4 mm²
2 x AWG 20 to 14/1 x AWG 20 to 12
2 x 0,5 ... 1,5 mm²/1 x 0,5 ... 2,5 mm²
2 x AWG 20 to 16/1 x AWG 20 to 14
