6 MACHINE START UP AND USE
6.1

CONTROL BOARD DESCRIPTION

Our rolling machines are provided with an electronic start/stop circuit board with
control treadle (except for CHDIL35M and CHDIL42M models, which do not have a
treadle).
The picture below shows the board's control buttons.
START – start rollers
D)
STOP – stop rollers
E)
F) PILOT LIGHT - moving rollers
When the treadle lies on the floor you can also simply press and release the control treadle
to start and stop the rollers.
6.2 WORKING PHASE
6.2.1 Thickness regulation
While the machine is not working, it is always possible to adjust the dough thickness
parameters.
In order to do this, use the top and bottom rollers' regulation levers.
(C)
A
O N OFF
(D)
(B)
- 38 -
C
Leva regolazione rulli
(A)
B
