3 - TECHNICAL SPECIFICATIONS AND PERFORMANCE

Operating conditions:
- In operation: pressure = 1.45 bars
- Stopped: pump maximum pressure
Values are given ±10%
Electrical data
Max. flow
Maximum pressure
Power cable
Level of protection
Max.water temperature
Max. ambient temperature
Rated impulse withstand voltage
4 - DESCRIPTION (fig.1)
1 - « On » indicator (GREEN indicator)
2 - « Reset » button (RESET indicator)
3 - Pump in operation indicator (YELLOW indicator)
4 - Alarm indicator (lack of water or malfunction) (RED
indicator)
5 - Exit with 1" male threaded connector
6 - Supply cable
7 - Pump connection cable
8 - Entry with 1"¼ female threaded connector
5 - PREPARATION - FIRST USE
The Tecnotronic is assembled on the delivery port of
the pump by screwing the 1"¼ female entry connector
(8) onto the male thread of the pump. If the pump has
a different exit from a 1"¼ male one, an intermediate
connector (provided) must be used (fig.2). After fitting
the Tecnotronic, connect the connection cable (7) to
the pump.
Before connecting the suction hose to the pump, fit a
filter to stop impurities to the suction hole of the pump.
The use of the filter is necessary to prevent any da-
mage to the Tecnotronic and consequently any opera-
ting problems.
Warning: Before use, it is necessary to fill the
pump and the suction hose completely with
water, in order to allow priming. In cases
where the water level is lower than the pump, then a
suction hose with a non-return valve must be
used. This allows them to be filled for the first use
and prevents them from emptying when the pump
stops automatically, thus avoiding any problems when
the pump is restarted.
Tecnotronic
220-240V~ - 50Hz - 10A
10 000 l/h
10 bars
H07 RN-F - 1,2m min.
IP55
35°C
55°C
2500V
The Tecnotronic system is delivered with supply
cables. Connect the supply cable (6) to the electricity
supply. If the suction phase does not start within 120
seconds, the pump stops automatically and the cause
of the malfunction must be determined.
6 - PANEL AND INDICATORS
The Tecnotronic is equipped with a control panel with
three luminous diodes which indicate the operating
condition of the pump:
- GREEN INDICATOR (1): It comes on when the
Tecnotronic is connected to the electricity supply.
- YELLOW INDICATOR (3): Lights up when the pump
starts and goes out when it stops.
- RED INDICATOR (4): Lights up when operation is
prevented due to a lack of water at suction or if the
pump breaks down.
- RESETTING BUTTON (RESET - 2): This serves to
restart the pump when a regular water supply has
been re-established.
NB :In the case where it does not start up, always
check that the suction hose is full of water.
