To Set The Timer - Panasonic CS-E18RD3EAW Bedienungsanleitung

To ensure optimal performance of the unit,
cleaning has to be carried out at regular
intervals. Please consult authorised dealer.
• Switch off the power supply before cleaning.
• Do not touch the aluminium fi n, sharp parts
may cause injury.
• Do not use benzine, thinner or scouring
powder.
• Use only soap ( pH 7) or neutral household
detergent.
• Do not use water hotter than 40 °C.
For seasonal inspection after extended
non-use
• No obstruction at air inlet and air outlet
vents.
• These units are mounted inside the ceiling.
It uses external air intake vent and air
outlet vent to operate. Please consult your
nearest dealer for seasonal inspection.
• After 15 minutes of operation, it is normal to
have the following temperature difference
between air inlet and air outlet vents:
COOL: ≥ 8 °C HEAT: ≥ 14 °C
For extended non-use
• Activate HEAT mode for 2~3 hours to
remove moisture left in the internal parts
thoroughly to prevent mould growth.
• Turn off the power supply.
NON SERVICEABLE CRITERIAS
TURN OFF POWER SUPPLY then please consult
authorised dealer under the following conditions:
• Abnormal noise during operation.
• Water/foreign particles have entered the remote
control.
• Water leaks from Indoor unit.
• Circuit breaker switches off frequently.
• Power cord becomes unnaturally warm.
• Switches or buttons are not functioning properly.
F569921-SA0215-0.indb 7 F569921-SA0215-0.indb 7

To set the timer

Daily timer setting
To turn ON or OFF the unit at a preset time.
• When ON timer is set, the unit may start early
• Timer operation is based on the clock set in
• The timer closest to the current time will be
• If timer is cancelled manually or due to power
Process Black Process Black
TIMER/CLOCK
MODE UP
1
OFF/ON DOWN
2
CLOCK
MODE
1 Press TIMER to enter timer mode
• Press once to change the display from
clock to timer or vice-versa.
• Press for 4 seconds to change the display
from daily timer to weekly timer or vice-
versa.
2 Select ON or OFF
timer
3 Set the time
4 Confi rm
CANCEL
• To cancel, press .
before the actual set time in order to achieve
the desired temperature on time.
the remote control and repeats daily once set.
activated fi rst.
failure, you can restore the previous setting
SET
by pressing .
SELECT
3
SET
4
CANCEL
Example:
OFF at 22:00
OFF/ON
UP
DOWN
SET
7
