Removing The Cover - KIKKA BOO GROOVY Gebrauchsanweisung

III. INSTALLING YOUR CHILD CAR SEAT AND SECURING YOUR CHILD FOR GROUP III(22KG-36KG)
Check and make sure there is no twist of the belt. Insert the metal tongue of carbelt into the carseat buckle until you hear a clear "click".
( g.3.5)
Warning! Make sure your child arms are above both diagonal and lap belt. ( g.3.6)
How to use Plus FIT
Press the Plus FIT release button, push Plus FIT connection backward to the longest position.( g.3.1)
Push Plus FIT connector to the xed point on the car till hear the crisp voice "ka", the button turns to green, then push forward to the
baby car seat to see if it is xed strongh enough and whether it is close to the rear seat back of the car.( g.3.2)
INSTALLING YOUR CHILD CAR SEAT AND SECURING YOUR CHILD FOR GROUP III (22KG-36KG)
1. lnstallation method 1:3-point safety belt +FIX
Routing the diagonal and lap belts correctly.
Make sure there is no twist of car belt. Route the diagonal belt on the shoulder of your child and lap belt under the armrest of car seat on
one side. Make sure lap belt must go under armrest,diagonal belt must over the upper armrest.( g.3.7)
Shake the seat to see if it is xed strong enough and whether the
Plus FIT connector fall o . Please follow above procedure install again.( g.3.3) 11.4 Press Plus FIT release button, the Plus FIT system can
be released.
( g.3.4)
2.Iinstallation method 2: 3-point safety belt only ( g.4)
Routing the diagonal and lap belts correctly
2.1. Seat your child on the booster seat.
2.2. Secure the seatbelt as shown in the diagram.
Make sure the seatbelt is not twisted.It is important.
2.3. Ensure that the lap section is worn low down and rmly engaged with the pelvis.
2.4. The diagonal belt must pass over the child the neck.
2.5. Ensure that the seat belt straps are not twisted.
2.6. Remove the excess slack from both the lap and diagonal belts by pulling them tight.
Warning! Make sure your child arms are above both diagonal and lap belt. ( g.3.6)
IV. REMOVING THE COVER
Remove the base cover by rasing the cover from down to up.( g.4)
Cleaning the cover
This child car seat must be used with seat cover as seat cover is an integral part of child car seat. It plays an important role in ensuring
that the system works properly. Make sure that only approved replacement cover by manufacturer could be used.
Daily cleaning and care instruction for cover.
Hand wash the cover in cold or warm water. Do not dehydrate. Suggest to use towel to absorb water and hang dry.
Note:
• Do not use detergent that contains chlorine bleach.
• Do not use washing machine, dehydration machine and dryer.
ENGLISH
