Comelit UT1010 Programmieranleitung Seite 13

ALWAYS move to version 1.1.1 FIRST and then update to the desired higher version.
2. The update packages consist of 2 files.
Simplebus 2
1. First install the file Us2x_UAPP_HW0x0002_v1.1.1.vpk (at the end of the update the LED with the bell
symbol will be lit steadily in red)
2. Next, install the file Us2x_AUDI_HW0x0002_1.1.1.vpk
Both files must be used and installed in this order.
Simplebus 1
1. First install the file Us1x_UAPP_HW0x0002_v1.1.1.vpk (at the end of the update the LED with the bell
symbol will be lit steadily in red)
2. Next, install the file Us1x_AUDI_HW0x0002_1.1.1.vpk
Both files must be used and installed in this order.
Restore backup
If the audio module is replaced, all programming is imported (only available if at least one additional module is
connected via flat cable). The procedure should be completed within one hour of removal of the old module
To restore the module configuration:
1. select it
2. right-click on the description (a pop-up with 5 sub-menus will appear)
3. select "Recovery backup"
13
