BUTTONS
AUDIO MODULE, MODULE 1... MODULE 31
• Button: select the button to program, referring to the images
• Function: this option is used to assign a different action to each module button
◊ None: no action (default)
◊ Audio call: when the button is pressed, an audio call is made to the address entered in the "Address"
field (from 1 to 240). The "Number of calls" field also appears, in which you can select the number of
calls to make to the address entered in the "Address" field (System settings or from 1 to 10)
◊ Local output control: when the button is pressed, the output set in the "Output" field is activated (SE
output for the module or Relay output for the module)
OUTPUTS
SE OUTPUT
• Function: select the command which activates the SE output for the audio module
◊ Lock-release: every lock-release command activates the output
◊ Actuator control: every actuator command with the address set in the "Address sent by external
unit" field activates the output
◊ Call sent: every call sent activates the output
• Activation
◊ Local output control (non-editable)
• Output
◊ SE (non-editable)
• Enable tones: a confirmation tone is emitted when the output is activated for the time period set in the
"Activation time (sec.)" field

RELAY OUTPUT

• Function: select the command which activates the Relay output for the audio module
◊ Lock-release: every lock-release command activates the output
◊ Actuator control: every actuator command with the address set in the "Address sent by external
unit" field activates the output
◊ Call sent: every call sent activates the output
• Activation
◊ Local output control (non-editable)
• Output
◊ Relay (non-editable)
• Enable tones: a confirmation tone is emitted when the output is activated for the time period set in the
"Activation time (sec.)" field
EVENTS
You can set the execution of several functions when specific events occur. Up to 20 events can be set.
EVENTS
• No.: select the progressive number of the event
• Action: select the action triggering the event
◊ None: no action (default)
◊ Call sent: if a call is sent to a door-entry phone with an address that falls within the values entered in
the "From address" and "To address" fields, it triggers the event specified in the "Activation" field
◊ Lock-release: if a lock-release command is sent from a door-entry phone with an address that falls
within the values entered in the "From address" and "To address" fields, it triggers the event specified
in the "Activation" field
◊ Actuator control: if an actuator command is sent with an address that falls within the values entered in
the "From address" and "To address" fields, it triggers the event specified in the "Activation" field
• Activation: action triggered after the event specified in the "Action" field occurs
◊ Local output control: activates the output set in the "Output" field (SE output for the module or Relay
