FIG. 6 USE AS AN AMPLIFIER FOR 4 SATELLITE LOUDSPEAKERS AND A SUBWOOFER USING AN ADDITIONAL 1-CHANNEL
AMPLIFIER (EDITION MONO)
(1) To the car radio, front left output
(2) To the car radio, front right output
(3) To the car radio, rear left output
(4) To the car radio, rear right output
(5) Front left loudspeaker
(6) Front right loudspeaker
(7) Rear left loudspeaker
(8) Rear right loudspeaker
(9) Subwoofer
FIG. 7 OPERATING ELEMENTS AND IN/OUTPUTS
(1) Low-level input
(2) Channel mode selector switch
(3) Input-level control
(4) Cross-over frequency control for low pass / high pass
(5) Linear (FULL) / low pass filter (LPF) / high pass filter (HPF) option switch
(6) Bass-booster control
(7) Low level outputs (channel 3/4)
