2.7 Contaminated Refrigerants
The Ultima ID Pro™ includes the ability to detect and analyze the composition of many
common R400 Series refrigerants in addition to R22, R32, R134a and Hydrocarbons (HC).
In the event that the Ultima ID Pro™ determines that the primary refrigerant in the system or
cylinder is one of the measured refrigerants, the results will display as follows in (Figure 11).
Pressing the 'MORE' button will display the detail screen shown in (Figure 12). If the blend
or refrigerant mixture is not recognized, the screen shown in (Figure 13) will be displayed.
Refer to section 2.10 Print the Test Results & Channel Data to print.
R410A
CONTAMINATED
PRINT
Figure 11
2.8 Pure Refrigerants
The Ultima ID Pro™ has the ability to Identify the following refrigerants: R12, R1234yf,
R408A, R409A, R417A, R421A, R421B, R422A, R422B, R422C, R427A and
Hydrocarbons (HC). All Identified refrigerants will display with "Purity Unknown" as the
analyzer cannot yield additional information regarding the composition (Figure 14). Refer to
2.12 Channel Data Modelling for additional information regarding Identified Refrigerants.
The instrument can also, Identify and Analyze the component content of pure R134a, R22,
HC (Hydrocarbons), R404A, R407C and R410A. Analysis of analyzed pure blend
refrigerants will yield additional data regarding the composition of the refrigerant sample. The
Ultima ID Pro™ will display the blend refrigerant type as shown in (Figure 15). Pressing the
'MORE' button will display the detail screen shown in (Figure 16). Refer to section 2.10
Print the Test Results & Channel Data to print.
NOTE:
Hydrocarbons (HC) encompass R600, R600A and R290 and this machine cannot
differentiate between Hydrocarbons.
Manual Part Number:
5-06-7000-70-2
RESULTS -
0.0% AIR
-
R410A
R22
MORE
BACK
Figure 12
REFRIGERANT
R12
PURITY UNKNOWN
Figure 14
98.7%
1.3%
PRINT DONE
0.0% AIR
PRINT DONE
Manual File:
MN-A-0289 Rev. E
0.0% AIR
UNKNOWN
REFRIGERANT
PRINT DONE
Figure 13
Page 2-19
