When the unit has completed a successful Air Calibration, the analyzer is then ready for gas
testing. The unit will display the screen shown in (Figure 7). Determine if you are Vapor
Sampling or Liquid Sampling and make sure the proper hose assembly is connected to
complete your required form of testing. Section 2.4 Vapor Sampling and 2.5 Liquid
Sampling outline proper procedure for both forms of testing.
Connect the hose to the tank or system, open the valve if connecting to a tank, and then
press 'TEST'. The Ultima ID Pro™ will display the screen shown in (Figure 8). Before the
test is completed the screen in (Figure 8a) will appear to indicate the test is nearly complete.
1 – CONNECT HOSE
2 – OPEN VALVE
3 – PRESS TEST
OFF
2.4

Vapor Sampling

Vapor sampling is the most common method used for identifying refrigerants using the Ultima
ID Pro™. It is a simple process requiring the operator to take these 4 steps:
1) Connect the Low Pressure Vapor Sampling Hose to the Low Side Vapor port
of the system or cylinder.
2) Open the low side valve of the cylinder and press 'TEST' (Figure 7).
3) When the test is complete, close the low side valve of the cylinder and
disconnect the hose from the cylinder.
4) Disconnect the hose from the Ultima ID Pro™ for storage.
Manual Part Number:
5-06-7000-70-2
- READY -
HELP TEST
Figure 7
ANALYZING THE
REFRIGERANT
Figure 8a
MN-A-0289 Rev. E
- TESTING -
THIS WILL ONLY
TAKE 120 SECONDS
- PROGRESS -
Figure 8
