5.2.2 Network Status LED

LED Status
OFF
1 Hz
ON
1 Hz green/red Self-test

5.2.3 Error LED

LED Status
1 Hz
ON
1 Hz green/red Self-test
Printed in the Federal Republic of Germany
06/27/2017
All manuals and user guides at all-guides.com
Cause
Not powered,
no IP address
No connections
Connected
Cause
Connection Timeout
Duplicate IP
TR - ECE - BA - DGB - 0073 - 07
Description
Device is not powered
or does not have an IP address.
Device has no established connections,
but has obtained an IP address.
The device has at least one established
connection, e.g. to the Message Router.
Valid, while the device is performing its power
up testing.
Description
One or more of the connections in which this
device is the target has timed out. This state
is left only if all timed out connections are re-
established or if the device is reset.
The device has detected that its IP address is
already in use
Valid, while the device is performing its power
up testing.
