7.6.3.3 Attribute 0x0C, Direction Counting Toggle

Direction Counting Toggle sets the counting direction of the measuring
system:
BOOL
Access Value Description
Set/Get
Connection path, Packed EPATH with 8 bit class
0x20
Logical Type
= Class
So that this attribute is accepted and saved permanently, 0x70 Accept Parameter
must be performed.

7.6.3.4 Attribute 0x64, Position Value

Position Value returns the current position of the measuring system as binary
coded value:
ULINT, read only
Byte 0
7 0
CEx-65 2 - 2
7 0
COx-65 2 - 2
Connection path, Packed EPATH with 8 bit class
0x20
Logical Type
= Class
