1. Scope of use
The mechanical sweeper is intended for sweeping
level and dry areas such as entrance drives,
terraces, yards, etc.
2. Safety information
Suitable measures must be taken to keep the
unit out of the reach of children.
Immediately replace defective parts.
Use only original replacement parts.
We will not be liable for any damage that results
from improper repairs and/or improper handling
of the unit (e.g. using the unit in ways for which it
was not intended).
The sweeping up of gel-like, liquid, combustible
or explosive substances is not permitted.
Do not use the mechanical sweeper to sweep up
glowing or harmful objects.
3. Layout and items supplied (Fig. 1)
1. Push bar
2. Adjustment nut for push bar
3. Fastening nuts for push bar
4. Setting screw for adjusting the height of the rear
pick-up brush
5. Feed-in brush
6. Setting screw for adjusting the height of the feed-
in brushes
7. Debris collector
4. Assembly (Fig. 2-5)
Note: You will fid the feed-in brushes in the debris
collector.
Follow the Figures 2 to 5 for the assembly. The feed-
in brushes are fastened to the locating plates with 3
screws each.
5. Technical data
Working width
Debris collector
Sweeping capacity (at 3-4 km/h) approx. 2800 m
Size 830 x 685 x 330 mm
Weight
14.01.2009 10:46 Uhr
6. Operation (Fig. 5)
When the mechanical sweeper is pushed, the feed-in
brushes (B) and the pick-up brushes (C) are set in
rotation by the belt drives (A).
The rotating feed-in brushes (B) sweep the dirt to the
center. The two counter-rotating pick-up brushes (C)
convey the dirt into the debris collector (Fig. 1/7).
7. Adjusting the feed-in brushes and
the pick-up brushes
The rear brush can be adjusted to 5 different heights
(Fig. 6/Item D) and the feed-in brushes can be
adjusted infinitely (Fig. 7/Item E) as required.
8. Emptying the debris collector (Fig. 8)
After sweeping up metal, glass or sharp objects,
wear heavy-duty work gloves when emptying the
debris collector.
9. Adjusting the height of the push bar
(Fig. 9)
Remove the adjustment nuts (2) and the relevant
screws. Select one of the three holes (F) as required,
then re-tighten the adjustment nuts (2) and the
relevant screws. The push bar can be set to three
different heights over a range of approximately 97 cm
- 91 cm - 86 cm.
10. Ordering spare parts
Please provide the following information on all orders
for spare parts:
Model/type of tool
Article number of the tool
ID number of the tool
Number of the required spare part
For our latest prices and information please go to
www.isc-gmbh.info
80 cm
35 l
2 /h
11,6 kg
