G (Ground)
Notice: All the connectors marked G or GND are common.
i
Connect the ground side of the alarm input and/or alarm output to the G (Ground)
connector.
AO (Alarm Output)
The camera can activate external devices such as buzzers or lights. Connect the device to
the AO (Alarm Output) and G (Ground) connectors.

Connecting the Power

1. 12VDC model
• Connect power of 12VDC for the camera.
• Connect the positive (+) pole to the '+' position and the negative (-) pole to the '-'
position. Be careful not to reverse the polarity when you connect the power cable.
2. PoE & 12VDC model
• Connect power of 12VDC for the camera.
• Connect the positive (+) pole to the '+' position and the negative (-) pole to the '-'
position. Be careful not to reverse the polarity when you connect the power cable.
If you use PoE to supply power to the camera, you must use the PoE (Power over
Ethernet) injector provided by the manufacturer.
