Connecting Alarms

A1,A2,A3,A4 (Alarm Input 1,2,3,4)
You can use external devices to signal the camera to react on events. Mechanical or
electrical switches can be wired to the A1,A2,A3,A4 (Alarm Input 1,2,3,4) and G (Ground)
connectors.
G (Ground)
Notice: All the connectors marked G or GND are common.
i
Connect the ground side of the alarm input and/or alarm output to the G (Ground)
connector.
AO (Alarm Output)
The camera can activate external devices such as buzzers or lights. Connect the device to
the AO (Alarm Output) and G (Ground) connectors.

Connecting the Power

Connect power of 12VDC for the camera.
When using a 12VDC adapter, connect the positive (+) pole to the ' + ' position and the
negative (-) pole to the ' - ' position.
Use satisfy clause 2.5 of IEC60950-1/UL60950-1 or Certified/Listed Class 2 power source
only.
• Be careful not to reverse the polarity when you connect the power cable.
Network Connection & IP assignment
The eneo scanning device tool is used to locate all eneo network cameras in a local net-
work. The tool does not need to be installed with a setup program. The program exe-file
can be started directly from the CD with a simple double click to use the program.
