Getting Ready To Build - Dremel DigiLab 3D45 Original Bedienungsanleitung

GETTING READY TO BUILD

OBSERVE ALL PROVIDED
WARNING
!
WARNINGS AND SAFETY
INSTRUCTIONS WHEN USING THE DREMEL 3D45.
Failure to do so may result in fire, equipment
damage, property damage or personal injury.
DO NOT TOUCH THE EXTRUDER
WARNING
!
TIP OR HEATED BUILD
PLATFORM DURING DREMEL 3D45 OPERATION OR
UNTIL IT HAS COOLED DOWN TO AT LEAST 60°C
(140°F). Contact with the extruder tip or build
platform during or after operation before tip and build
platform has cooled may result in personal injury.
USE ONLY DREMEL FILAMENT.
WARNING
!
Use of filament not authorized by
Dremel may result in equipment, property damage, or
personal injury.
DO NOT ADJUST EXTRUDER
WARNING
!
SETTING TO EXCEED THE
MAXIMUM RATED TEMPERATURE OF THE FILAMENT
TYPE BEING USED. Heating filament above
recommended range can cause emissions that may
result in personal injury.
DO NOT PULL THE FILAMENT
!
OUT. Doing so may damage the
extruder.
LOADING/CHANGING FILAMENT
1. Start filament load/change process by tapping
"Filament" button on touchscreen. Extruder will
move to front right corner of print area and extruder
tip will begin to heat.
FIG. 1
Open
2. After extruder stops moving, open the 3D45 Lid for
3. If existing filament is loaded, cut existing filament
4. Remove Spool door by rotating it counter clockwise
Spool Holder
Filament
Close
440
better access to extruder.
near extruder intake and tap the arrow button on
touchscreen.
and remove existing spool if one is present, see
figure1.
Filament Guide Tube
5
6
