Dremel DigiLab 3D45 Original Bedienungsanleitung Seite 22

FIG. 2
5. Thread tip of new filament through guide tube,
place spool on spool holder, replace spool door by
aligning locking tabs and rotating clockwise, see
figure 1.
6. When you place a roll of Dremel filament into the
spool holder, the printer will auto-recognize the
filament type and adjust the printer settings to be
optimized for the filament you are using. (This will
bypass any print settings loaded in your sliced file).
NOTE: You have the option to enter advanced
printer mode to manually alter print settings after
you change filament. Please check all settings (if
manually entered) as improper settings may cause
prints to fail, property damage, or personal injury, see
"Filament Type and Settings" chart on page 23 or
on dremel3d.com for the latest chart.
NOTE: You also have the option to enter advanced
printer mode, which allows you to pull print settings
from the saved sliced file. This will prevent the
printer from altering its print settings. Please check
all settings prior to printing as improper settings
may cause prints to fail, property damage, or
personal injury.
7. If changing existing filament, 3D45 will
automatically purge existing filament.
8. When Feed Filament screen appears, tap the arrow
on touchscreen and thread filament coming from
guide tube into extruder intake until extruder feeds
through on its own, see figure 2.
NOTE: Ensure the gears inside of the extruder
have properly grabbed the filament before you
finish the filament change. You will feel a tug and
see the filament start to feed itself into the extruder
when this occurs.
Guide Tube Filament
9. Filament will be drawn into the extruder and begin
to exit from the hot extruder tip.
NOTE: Your Dremel 3D45 was tested by building
objects before leaving the factory. These test objects
may have been made with a different filament color
than you are using. Therefore, a small amount of
filament may be remaining in the extruder.
10. When new filament appears from extruder tip, tap
"done" on touchscreen to complete filament load
process, return to main menu, and calibrate
extruder. Carefully remove excess filament without
touching hot extruder tip. If necessary, carefully
remove debris from extruder tip with needle nose
pliers.
!
WHEN CLEARING DEBRIS. DREMEL 3D45 WILL NOT
WORK PROPERLY WITH A DAMAGED EXTRUDER TIP
AND WILL REQUIRE REPLACEMENT.
11. Close 3D45 lid and door.
22
Filament Guide Extruder intake
USE EXTRA CARE NOT TO
DAMAGE THE EXTRUDER TIP
N
