Operating Instructions
SNPS-90 Notebook Power Supply
Item No. 2266529
Intended use
Use the product to charge notebooks. Operate the product with a household socket.
The product is protected against overload and short-circuiting.
It is intended for indoor use only. Do not use it outdoors. Contact with moisture, e.g. in
bathrooms, must be avoided under all circumstances.
For safety and approval purposes, you must not rebuild and/or modify this product. If you use
the product for purposes other than those described above, the product may be damaged. In
addition, improper use can result in short circuits, fires, electric shocks or other hazards. Read
the instructions carefully and store them in a safe place. Make this product available to third
parties only together with its operating instructions.
This product complies with the statutory national and European requirements. All company
names and product names are trademarks of their respective owners. All rights reserved.
Delivery content
• Power supply • 9x Plugs
• AC cord • Operating instructions
Up-to-date operating instructions
Download the latest operating instructions at www.conrad.com/downloads or
scan the QR code shown. Follow the instructions on the website.
Explanation of symbols
The symbol with the lightning in the triangle is used if there is a risk to your health,
e.g. due to an electric shock.
The symbol with the exclamation mark in the triangle is used to indicate important
information in these operating instructions. Always read this information carefully.
Safety instructions
Read the operating instructions carefully and especially observe the safety
information. If you do not follow the safety instructions and information
on proper handling in this manual, we assume no liability for any resulting
personal injury or damage to property. Such cases will invalidate the warranty/
guarantee.
a) General information
• The device is not a toy. Keep it out of the reach of children and pets.
• Do not leave packaging material lying around carelessly. This may become
dangerous playing material for children.
• Protect the appliance from extreme temperatures, direct sunlight, strong jolts,
high humidity, moisture, flammable gases, steam and solvents.
• Do not place the product under any mechanical stress.
• If it is no longer possible to operate the product safely, take it out of operation and
protect it from any accidental use. Safe operation can no longer be guaranteed
if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor ambient conditions or
- has been subjected to any serious transport-related stresses.
• Please handle the product carefully. Jolts, impacts or a fall even from a low height
can damage the product.
• Consult an expert when in doubt about the operation, safety or connection of
the appliance.
• Maintenance, modifications and repairs must only be completed by a technician
or an authorised repair centre.
• If you have questions which remain unanswered by these operating instructions,
contact our technical support service or other technical personnel.
b) Connected devices
• Also observe the safety and operating instructions of any other devices which are
connected to the product.
c) Product
• Never leave the product and the connected device unattended during use.
• The accident prevention regulations of the association of commercial insurance
for electrical systems and equipment should be observed in commercial facilities!
• Keep all provided small parts away from children and pets; there is a risk of
swallowing.
• Never use the product immediately after it has been brought from a cold room
into a warm one. The condensation generated could destroy the product. The
power supply unit also involves danger to life by electric shock! Allow the device
to reach room temperature before connecting and using it. This may take several
hours.
• Never pour any liquids over electrical devices or put objects filled with liquid
right next to the device. If liquid or an object enters the interior of the device
nevertheless, first power down the respective socket (e.g. switch off circuit
breaker) and then pull the mains plug from the mains socket. Do not operate the
product anymore afterwards, but take it to a specialist workshop.
• Disconnect the power supply from the wall socket and the connected appliance
when not in use.
• The power supply generates heat during use. Ensure sufficient ventilation and do
not cover the power supply during use.
• The wall socket used for connecting the power supply must be easily accessible.
• Only connect the power supply to a normal mains socket connected to the public
supply. Before connecting, check whether the voltage stated on the power supply
complies with the voltage of your electricity supplier.
• Never connect or disconnect power supplies if your hands are wet.
• Never unplug the power supply from the mains socket by pulling on the cable;
always use the grips on the plug.
• When setting up the power supply, make sure that the cable is not pinched,
kinked or damaged by sharp edges.
• Always lay the cables so that nobody can trip over or become entangled in them.
This poses a risk of injury.
• For safety reasons, disconnect the power supply from the mains socket during
storms.
• If the power supply is visibly damaged, do not touch it. Risk of fatal injury due to
electric shock!
First turn off the power to the power outlet that the power supply is connected to
(flip off the fuse and then turn off the residual current operated circuit breaker to
disconnect the power outlet at all phases).
Now disconnect the power supply from the power outlet. Do not use it again.

Operation

NOTICE
Prevent product damage!
• Observe the operating voltage and polarity of the appliance to be connected.
• Do not connect appliances that require more power than the power supply can
deliver.
• Before connecting and disconnecting appliances, disconnect the power supply from
the mains.
• Do not short-circuit contacts.
a) Selecting and installing a plug
Every plug has an imprinted letter.
Follow the below table to select a suitable plug for your device.
The charging port of the device you intend to charge must correspond to the polarity as
indicated in the table.
Letter Dimensions
P inner: Ø 2.5 mm
outer: Ø 5.5 mm
E pin: Ø 1.4 x 6.5 mm
G pin: Ø 1.0 mm
outer: Ø 5.0 mm
X inner: Ø 1.7 mm
outer: Ø 5.5 mm
N pin: Ø 0.9 mm
outer: Ø 7.9 mm
Q-V2 pin: Ø 0.6 mm
outer: Ø 7.4 mm
T inner: Ø 1.7
outer: Ø 4.75 mm
AG pin: Ø 0.6 mm
outer: Ø 4.5 mm
AH inner: Ø 3.3 x 6.6 mm
outer: Ø 4.6 x 11 mm
Polarity Suitable for
Fujitsu, Acer, Asus, Compaq, Gateway,
HP, IBM, Panasonic, Samsung, Sharp,
Toshiba, Hitachi
Fujitsu, Panasonic, Sony, Samsung, Dell
Samsung
Acer
IBM, Lenovo
HP
HP Pavilion series
HP Envy TouchSmart
Lenovo
