Quick Setup Guide
1.1 System Board Layout
Wake-On-KB/Mouse
(JP1)
CN4
4
2
+12V power
(ATXP1)
3
1
COM 1
(CN2)
Parallel (CN6)
VGA (CN1)
Wake-On-USB KB
for USB 1/2/3/4 (JP9)
CN3
CN3
CN7
Game/MIDI
2
1
(J6)
2
15
I/O
CN5
chip
Front audio (J2)
IrDA (J11)
AC'97
TAD (J7)
S/PDIF-out
(J1)
CD-in (J8)
Realtek
RTL8100
Square denotes pin 1
6
manuals search engine
Intel
845G
GMCH
9
COM 2
(J13)
1
DDR SDRAM
Wake-On-Ring (J12)
DIMM 1
AGP Slot
PCI Slot 1
CPU FSB
PCI Slot 2
select (JP4)
PCI Slot 3
PCI Slot 4
Firmware
Hub
PCI Slot 5
Wake-On-USB KB for
PCI Slot 6
USB 5 & 6
(J14)
NB76-BL
(Supports onboard LAN)
CPU fan
Second
(J18)
fan (J19)
ATX main
power (PL1)
DIMM
Standby
Power LED
IDE 1
FDD (J21)
(J24)
DDR SDRAM
DIMM 2
IDE 2 (J22)
Clear CMOS (JP7)
Wake-On-
Intel
LAN (J23)
ICH4
Chassis
fan (J25)
Battery
USB 5/6 (JP8)
RESET
SPEAKER
HD-LED
J20
G-SW
PWR-LED
ATX-SW
G-LED
