UNILITE ATEX-FL4 Bedienungsanleitung

FEATURES
• High power 150 Lumen white Cree LED, 6500k
• Intrinsically safe for use in hazardous locations
• Industrial polycarbonate construction
• Durable rubberised head and non-slip hand grips
• Removable pocket clip attachment included
• Easy press tactical rubberised micro switch
• Polycarbonate lens and smooth reflector for long beam
• Safety release valve to allow hydrogen gases to escape
• Secure screw fastening battery compartment
• Chemical and corrosion resistant
• IP67 dust & water proof (3m submersible)
BATTERIES - 4 x AA Alkaline or Ni-MH batteries (not included)
WEIGHT - 115g without batteries
DIMENSIONS - 47 x 47 x 174mm
CERTIFICATIONS
Class I Div 1 Grp ABCD / Class II Div 1 Grp EFG
Class III / Temperature Code T4 IP67
File number: E324236
II 1G Ex ia IIC T4 IP67
DEMKO 13 ATEX 1302999X Rev.1
Ex ia IIC T4 Ga
IECEx UL 13.0013X Iss.1
Approved - 0518
Approved
Approved
Address: No. 1, Alley 2, Lane 110, Sec. 4, Hsi-Men Road, North District, Tainan City, 704 Taiwan
STANDARDS
UL 913, 7th Edition
CAN/CSA C22.2 No.157-92, Reaffirmed 2013
EN 60079-0:2009 Edition
EN 60079-11:2012 Edition
EN 60079-26:2007 Edition
IEC 60079-0:2007-10, 5th Edition
IEC 60079-11:2011, 6th Edition
IEC 60079-26:2006, 2nd Edition
Directive 2014/34/EU
www.unilite.co.uk
ANSI FL1 Standard
HIGH
LOW
OPERATION
Press tail switch to operate.
Switch Sequence:
HIGH > LOW > OFF
ACCESSORIES
- Pocket Clip (included)
- Helmet Clamp available
BATTERY INSTALLATION
To replace the batteries, use a cross-head screwdriver to unlock the battery
compartment on the side of the flashlight. Ensure that only batteries of
the types specified below are used. Replace batteries taking note of the
polarity markings. Then ensure that the battery compartment is closed
securely.
SAFETY WARNING - Do not attempt to open in hazardous locations.
Unilite cannot be held responsible for the use of mixed or incorrect
batteries in our ATEX products.
Battery Replacement:
Use only battery types below:
Alkaline type NiMH type
Energizer E91 Energizer NH15-2300
Duracell MN1500
Rayovac 815
Ansmann 5015548
Ansmann 1502-0002
ADVICE & IMPORTANT INFORMATION!
DO NOT OPEN THIS DEVICE IN HAZARDOUS LOCATIONS.
Only use the battery brands mentioned in these instructions.
Always use high-quality Alkaline 1.5v AA batteries and high quality Ni-MH batteries.
Do not attempt to recharge Ni-MH batteries inside the flashlight.
Disposable battery life is affected by different battery brands, different ambient temperatures and
different lighting modes. To reduce the RISK OF EXPLOSION do not mix new batteries with used
batteries, or mix different battery brands.
If not using the torch for 3 weeks or more, be sure to remove the batteries to avoid battery depletion
or leakage. Battery leaks are not covered under warranty.
Protect batteries from heat, intense sunlight, fire, water and moisture. If a battery is damaged, fluids
can leak out. AVOID contact as this can lead to skin irritation and/or burns. If skin contact occurs,
rinse thoroughly with water. If irritation persists, seek medical advice.
Do not look directly at the LED or shine directly in other peoples eyes.
The LED will become warm when switched on; do not touch and do not place face down on any
surface – risk of fire!
Do not use the device if there is any visible damage to the housing, lens or switch. Check for any
damage before each use.
This product is water proof to IPX7 – 3m SUBMERSIBLE . If the product has been affected by
excessive damp or moisture, remove the batteries and leave the unit open and allow to dry out
completely before using.
If the batteries are installed and the device does not work, try checking for the following: (1) Press
the switch button several times. (2) Check that the batteries are inserted the correct way around
according to polarity markings. (3) Check there is no debris on the contacts that might affect the
battery connection. (4) Check there is no water or dampness in the unit, if so, allow it to fully dry
out and try again.
If the product has been subjected to water deeper than 3m the warranty may be void.
This product has a 1 year standard warranty (or extended 2 years once registered online at WWW.
UNILITE.CO.UK/WARRANTY) against manufacturing faults and defects. It does not cover normal
wear and tear, modifications, accidental damage or poor maintenance. Unilite warranties do not
cover battery leaks.
Take care not to let the lens come into contact with hard/sharp objects, damage to the lens will
affect light output.
Children under 12 years of age should only use the product with adult supervision.
Do not disassemble or attempt to modify the product, this will void the warranty and can impair the
intrinsic safety and can be dangerous. Improper use or modification is not covered under warranty.
Do not dispose of this device in normal household waste. It must be disposed of via an authorised
disposal centre or at your local waste disposal unit.
Please re-use or recycle packaging where possible.
Keep these instructions for future reference or for subsequent possessors.
ATEX-FL4
150
235M 6H
Lumens
35
110M 69H
Lumens
