Description of the pictured components (Figure A - B)

1. Rotary Dosing Unit
2. Mounting part
3. Vario dosing valve
4. Electric connection rotary dosing unit
5. Vario dosing valve hydraulic connection
6. Servo controller with EtherCAT
7. Screws with sealing wax
8. Type label
9. Marking
10. Electric connection Dosing valve VARIO
11. Potentiometer for rotary dosing unit speed
12. Line filter choke

Assembly/installation

The product has to be set up or installed at the intended installation site under
consideration of the conditions that follow.
 The applicable legal provisions on site have to be clarified and compliance
must be assured.
 The available space has to be clarified prior to installation/setup of the product
in order to ensure ongoing safe operation for the personnel and product. The
product has to be set up/installed so that ongoing safe operation is assured.
 The product may only be set up and put into operation by qualified personnel
with corresponding special training.
 The product is designed for use in rooms protected against the effects of
weather (industry standard).
 Operation and storage in aggressive, excessively damp environments or
outdoors may lead to corrosion damage.
 The valves can be installed in any position.
CAUTION
Due to the sharp and thin edges, there is a risk of injury when handling
thin nozzles.
