Functionality
The function of the rotary feeder rotary dosing unit is the radial wetting of inside
component surfaces. This function applies to all variants of the rotary unit. The
medium is fed to the rotary unit via the Vario dosing valve. The medium is
transported by the rotating shaft of the rotary dosing unit and ejected at the centrifuge
plate.

Technical data

Rotary Dosing Unit AXDV-R1
Centrifugal plate diameter [mm] 8
Lance length [mm]
Operation medium
Speed [rpm]
Hydraulic connection
Max. inlet operating pressure
Voltage [V]
Frequency [Hz]
Min. / Max. temperature [°C]
AKD
Nominal supply voltage [V AC]
Mains frequency [Hz]
Auxiliary power supply [V DC]
Rated input power [kW]
Rated input current [A]
AXDV-V1-EL
Auxiliary power supply [V DC]
Motor current [A]
50, 140
Grease or Oil
0 - 10'000
Internal thread 1/8"
BSP
Depending on the
material supply
used
230
50
10 / 40
1x120 up to 240 ±
10%
50 up to 400 ± 5%
24 ± 10%
1,2
at 1x 240V
5,0
24
0,77
16
10, 100, 160
Grease or Oil
0 - 10'000
Internal thread
1/8" BSP
Depending on the
material supply
used
230
50
10 / 40
