Copyright Notice:
No part of this installation guide may be reproduced, transcribed, transmitted, or trans-
lated in any language, in any form or by any means, except duplication of documentation
by the purchaser for backup purpose, without written consent of ASRock Inc.
Products and corporate names appearing in this guide may or may not be registered
trademarks or copyrights of their respective companies, and are used only for identifica-
tion or explanation and to the owners' benefit, without intent to infringe.
Disclaimer:
Specifications and information contained in this guide are furnished for informational use
only and subject to change without notice, and should not be constructed as a commit-
ment by ASRock. ASRock assumes no responsibility for any errors or omissions that may
appear in this guide.
With respect to the contents of this guide, ASRock does not provide warranty of any kind,
either expressed or implied, including but not limited to the implied warranties or condi-
tions of merchantability or fitness for a particular purpose. In no event shall ASRock, its
directors, officers, employees, or agents be liable for any indirect, special, incidental, or
consequential damages (including damages for loss of profits, loss of business, loss of
data, interruption of business and the like), even if ASRock has been advised of the pos-
sibility of such damages arising from any defect or error in the guide or product.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
The Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
"Perchlorate Material-special handling may apply, see
www.dtsc.ca.gov/hazardouswaste/perchlorate"
The terms HDMI™ and HDMI High-Definition Multimedia Interface, and the HDMI logo
are trademarks or registered trademarks of HDMI Licensing LLC in the United States and
other countries.
1
Downloaded from
www.Manualslib.com
manuals search engine

Werbung

Inhaltsverzeichnis
loading

Inhaltszusammenfassung für ASROCK H61M-HVGS

  • Seite 1 ASRock. ASRock assumes no responsibility for any errors or omissions that may appear in this guide. With respect to the contents of this guide, ASRock does not provide warranty of any kind, either expressed or implied, including but not limited to the implied warranties or condi- tions of merchantability or fitness for a particular purpose.
  • Seite 2: Inhaltsverzeichnis

    Chassis Fan Connector (CHA_FAN1) Clear CMOS Jumper (CLRCMOS1) SATA2 Connector (SATA2_0, Blue) PCI Express 2.0 x16 Slot (PCIE1, Blue) SATA2 Connector (SATA2_3, Blue) Power Fan Connector (PWR_FAN1) SATA2 Connector (SATA2_2, Blue) ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 3: Usb

    Please click “VIA HD Audio Deck” icon , and click “Advanced Options” on the left side on the bottom. In “Advanced Options” screen, select “Independent Headphone”, and click “OK” to save your change. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 4: Usb

    Please click “VIA HD Audio Deck” icon , and click “Advanced Options” on the left side on the bottom. In “Advanced Options” screen, select “Independent Headphone”, and click “OK” to save your change. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 5: Package Contents

    In case any modifications of this manual occur, the updated version will be available on ASRock website without further notice. You may find the latest VGA cards and CPU support lists on ASRock website as well. ASRock website http://www.asrock.com If you require technical support related to this motherboard, please visit our website for specific information about the model you are using.
  • Seite 6: Pci Express

    Pixel Shader 4.1, DirectX 10.1 with Intel Sandy Bridge CPU. ® - Max. shared memory 1760MB with Intel Ivy Bridge CPU. ® Max. shared memory 1759MB with Intel Sandy Bridge CPU. (see CAUTION 4) ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 7: 32Mb Bios

    - 2 x USB 2.0 headers (support 4 USB 2.0 ports) BIOS Feature - 32Mb AMI BIOS - AMI UEFI Legal BIOS with GUI support - Supports “Plug and Play” ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 8 - FCC, CE, WHQL - ErP/EuP Ready (ErP/EuP ready power supply is required) (see CAUTION 15) * For detailed product information, please visit our website: http://www.asrock.com WARNING Please realize that there is a certain risk involved with overclocking, including adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using the third-party overclocking tools.
  • Seite 9 ® Vista / XP. For Windows OS with 64-bit CPU, there is no such limita- tion. You can use ASRock XFast RAM to utilize the memory that Win- ® dows cannot use. The maximum shared memory size is defined by the chipset vendor and ®...
  • Seite 10 Real-Time Analysis of Your Data: With the status window, you can easily recognize which data streams you are currently transferring. 12. ASRock XFast RAM is a new function that is included into ASRock Ex- treme Tuning Utility (AXTU). It fully utilizes the memory space that cannot ®...
  • Seite 11 5v standby power efficiency is higher than 50% under 100 mA current consumption. For EuP ready power supply selection, we recommend you checking with the power supply manufacturer for more details. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com...
  • Seite 12: Cpu Installation

    CPU surface is unclean or if there is any bent pin on the socket. Do not force to insert the CPU into the socket if above situation is found. Other- wise, the CPU will be seriously damaged. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com...
  • Seite 13 1155-Pin Socket orientation key notch 1155-Pin CPU For proper inserting, please ensure to match the two orientation key notches of the CPU with the two alignment keys of the socket. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 14 Option (C.C.O.), which provides the flexible option to adopt three dif- ferent CPU cooler types, Socket LGA 775, LGA 1155 and LGA 1156. The white throughholes are for Socket LGA 1155/1156 CPU fan. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 15: Installing A Dimm

    Step 3. Firmly insert the DIMM into the slot until the retaining clips at both ends fully snap back in place and the DIMM is properly seated. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 16: Installing An Expansion Card

    Align the card connector with the slot and press firmly until the card is completely seated on the slot. Step 5. Fasten the card to the chassis with screws. Step 6. Replace the system cover. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 17 If you haven’t installed onboard VGA driver yet, please install onboard VGA driver from our support CD to your system and restart your computer. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 18 Click “Apply” or “OK” to apply these new values. G. Repeat steps C through E for the diaplay icon identified by the number one, two, three and four. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 19 PCs requires a secure connection to a compliant display. Due to the increase in manufacturers employing HDCP in their equipment, it is highly recommended that the HDTV or LCD monitor you purchase is compatible. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 20 Please be noted that the password, date, time, user default profile, 1394 GUID and MAC address will be cleared only if the CMOS battery is removed. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com...
  • Seite 21 (25-pin LPT1) SPD1 SPD2 SLCT SPD3 convenient connection of printer SPD4 (see p.2 No. 18) BUSY SPD5 ACK# SPD6 SPD7 devices. SLIN# PINIT# ERROR# AFD# ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 22 HDLED (Hard Drive Activity LED): Connect to the hard drive activity LED on the chassis front panel. The LED is on when the hard drive is reading or writing data. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 23 20-pin ATX power supply. To use the 20-pin ATX power supply, please plug your power supply along with Pin 1 and Pin 13. 20-Pin ATX Power Supply Installation ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 24 Please connect an ATX 12V power supply to this connector. (4-pin ATX12V1) (see p.2 No. 2) Serial port Header This COM1 header supports a serial port module. (9-pin COM1) (see p.2 No. 17) ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 25: Installing Windows

    A. Enter UEFI SETUP UTILITY Advanced screen SATA Configuration. B. Set the option “SATA Mode Selection” to [IDE]. ® STEP 2: Install Windows XP / XP 64-bit OS on your system. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 26 SATA Configuration. B. Set the option “SATA Mode Selection” to [IDE]. ® STEP 2: Install Windows 7 / 7 64-bit / Vista / Vista 64-bit OS on your system. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 27 It will display the Main Menu automatically if “AUTORUN” is enabled in your computer. If the Main Menu does not appear automatically, locate and double-click on the file “ASSETUP.EXE” from the BIN folder in the Support CD to display the menus. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 28: Einführung

    1. Einführung Wir danken Ihnen für den Kauf des ASRock H61M-HVGS / H61M-HVS Mother- board, ein zuverlässiges Produkt, welches unter den ständigen, strengen Qualitäts- kontrollen von ASRock gefertigt wurde. Es bietet Ihnen exzellente Leistung und robustes Design, gemäß der Verpflichtung von ASRock zu Qualität und Halbarkeit.
  • Seite 29: Spezifikationen

    ® Video-Technik (HD), Intel HD Graphics 2000/3000, Intel ® Advanced Vector Extensions (AVX) mit Intel Sandy Bridge- Prozessor ® - Pixel Shader 5.0, DirectX 11 mit Intel Ivy Bridge-Prozessor, ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 30: Rückseite

    - HD Audiobuchse: Audioeingang / Lautsprecher vorne / Mikrofon Anschlüsse - 4 x SATA2 3,0 GB/s-Anschlüsse, unterstützen NCQ-, AHCI- und „Hot Plug“ (Hot-Plugging)- Funktionen - 1 x Druckerport-Anschlussleiste - 1 x COM-Anschluss-Header - CPU/Gehäuse/Stromlüfter-Anschluss ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 31: Hardware Monitor

    - ASRock Extreme Tuning Utility (AXTU) Eigenschaft (siehe VORSICHT 6) - ASRock Sofortstart - ASRock Instant Flash (siehe VORSICHT 7) - ASRock APP Charger (siehe VORSICHT 8) - ASRock SmartView (siehe VORSICHT 9) - ASRock XFast USB (siehe VORSICHT 10)
  • Seite 32: Zertifizierungen

    7 / Vista™ / XP et- was Speicher zur Nutzung durch das System reserviert wird. Unter Win- ® dows OS mit 64-Bit-CPU besteht diese Einschränkung nicht. ASRock ® XFast RAM zur Nutzung des Speichers, den Windows nicht verwenden kann, einsetzen.
  • Seite 33 APP Charger. Installieren Sie einfach den ASRock APP Charger-Treiber; dadurch lädt sich Ihr iPhone wesentlich schneller über einen Computer- auf – genaugenommen bis zu 40 % schneller als zuvor. Der ASRock APP Charger ermöglicht Ihnen die schnelle Aufladung mehrerer Apple-Geräte gleichzeitig;...
  • Seite 34 Youtube-Videos in HD anzeigen und gleichzeitig Dateien herunterladen. Echtzeitanalyse Ihrer Daten: Über das Statusfenster können Sie schnell ermitteln, welche Datenströme zur Zeit übertragen werden. 12. ASRock XFast RAM ist eine neue Funktion, die beim ASRock Extreme Tuning Utility (AXTU) integriert ist. Sie ermöglicht die vollständige Nut- ®...
  • Seite 35: Einstellung Der Jumper

    Sie zuerst das System hoch. Fahren Sie es dann vor der CMOS-Löschung herunter. Bitte beachten Sie, dass Kennwort, Datum, Uhrzeit, benutzerdefiniertes Profil, 1394 GUID und MAC-Adresse nur gelöscht werden, wenn die CMOS-Batterie entfernt wird. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 36: Integrierte Header Und Anschlüsse

    SPD2 Kabels, mit dem Sie passende (siehe S.2 - No. 18) SLCT SPD3 SPD4 BUSY SPD5 Drucker auf einfache Weise ACK# SPD6 SPD7 anschließen können. SLIN# PINIT# ERROR# AFD# ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 37 Gehäuses. Die LED leuchtet, wenn das System in Betrieb ist. Die LED blinkt, wenn sich das System im Ruhezustand S1 befindet. Die LED schaltet sich aus, wenn sich das System in den Modi S3/S4 befindet oder ausgeschaltet ist (S5). ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 38 Motherboards anschließen möchten, verbinden Sie ihn bitte mit den Pins 1 – 3. Pins 1–3 anschließen Lüfter mit dreipoligem Anschluss installieren ATX-Netz-Header Verbinden Sie die ATX- Stromversorgung mit diesem (24-pin ATXPWR1) Header. (siehe S.2 - No. 4) ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 39 Anschluss die ATX 12V (4-pin ATX12V1) Stromversorgung an. (siehe S.2 - No. 2) COM-Anschluss-Header Dieser COM-Anschluss- Header wird verwendet, um (9-pin COM1) ein COM-Anschlussmodul zu (siehe S.2 - No. 17) unterstützen. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 40 Das Setup-Programm soll es Ihnen so leicht wie möglich machen. Es ist menüges- teuert, d.h. Sie können in den verschiedenen Untermenüs Ihre Auswahl treffen und die Programme werden dann automatisch installiert. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 41: Contenu Du Paquet

    1. Introduction Merci pour votre achat d’une carte mère ASRock H61M-HVGS / H61M-HVS, une carte mère très fiable produite selon les critères de qualité rigoureux de ASRock. Elle offre des performances excellentes et une conception robuste conformément à l’engagement d’ASRock sur la qualité et la fiabilité au long terme.
  • Seite 42 Quick ® ® Sync Video, Intel InTru 3D, Intel Clear Video HD ® ® Technology, Intel HD Graphics 2000/3000, Intel Advanced ® Vector Extensions (AVX) avec processeur Intel Sandy ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 43 - 4 x connecteurs SATA2, prennent en charge un taux de transfert de données pouvant aller jusqu’à 3.0Go/s, supporte NCQ, AHCI et « Hot Plug » (Branche ment à chaud) ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 44 - Utilitaire ASRock Extreme Tuning (AXTU) unique (voir ATTENTION 6) - ASRock l’Instant Boot - ASRock Instant Flash (voir ATTENTION 7) - Chargeur ASRock APP (voir ATTENTION 8) - SmartView (voir ATTENTION 9) - ASRock XFast USB (voir ATTENTION 10)
  • Seite 45 ® Vista / XP. Avec Windows OS avec CPU 64 bits, il n’y a pas ce genre de limitation. Vous pouvez utiliser ASRock XFast RAM pour accéder à la ® mémoire que Windows ne peut pas utiliser. La dimension maximum du memoire partage est definie par le vendeur ®...
  • Seite 46 ASRock Extreme Tuning Utility (AXTU). Site Web de ASRock : http://www.asrock.com O ASRock Instant Flash é um utilitário de flash do BIOS incorporado na memória Flash ROM. Esta prática ferramenta de actualização do BIOS permite-lhe actualizar o BIOS do sistema sem necessitar de entrar nos ®...
  • Seite 47 USB. Les performances réelles dépendent des propriétés du périphérique. 11. ASRock XFast LAN fournit un accès Internet plus rapide, avec les avan- tages suivants. Priorisation d’application LAN : Vous pouvez configurer votre priorité d’application idéalement et/ou ajouter des nouveaux pro- grammes.
  • Seite 48 CMOS. Veuillez noter que le mot de passe, la date, l’heure, le profil par défaut de l’utilisateur, 1394 GUID et l’adresse MAC seront effacés seulement si la batterie du CMOS est enlevée. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com...
  • Seite 49 (LPT1 25 broches) STB# SPD0 SPD1 SPD2 permet le raccordement (voir p.2 No. 18) SLCT SPD3 SPD4 BUSY SPD5 pratique de périphériques ACK# SPD6 SPD7 d’impression. SLIN# PINIT# ERROR# AFD# ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 50 Le voyant DEL clignote lorsque le système est en mode veille S1. Le voyant DEL est éteint lorsque le système est en mode veille S3/ S4 ou lorsqu’il est éteint (S5). ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com...
  • Seite 51 Si vous prévoyez de connecter le ventilateur de CPU à 3 broches au connecteur du ventilateur de CPU sur cette carte mère, veuillez le connecter aux broches 1-3. Installation de ventilateur à 3 broches Broches 1-3 connectées ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 52 (voir p.2 No. 2) En-tête de port COM Cette en-tête de port COM est utilisée pour prendre en charge (COM1 br.9) un module de port COM. (voir p.2 No. 17) ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 53 Si le Menu principal n’apparaît pas automatiquement, locali- sez dans le CD technique le fichier “ASSETUP.EXE” dans le dossier BIN et double- cliquez dessus pour afficher les menus. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 54: Contenuto Della Confezione

    1. Introduzione Grazie per aver scelto una scheda madre ASRock H61M-HVGS / H61M-HVS, una scheda madre affidabile prodotta secondo i severi criteri di qualità ASRock. Le prestazioni eccellenti e il design robusto si conformano all’impegno di ASRock nella ricerca della qualità e della resistenza.
  • Seite 55 - Pixel Shader 5.0, DirectX 11 con CPU Intel Ivy Bridge, Pixel ® Shader 4.1, DirectX 10.1 con CPU Intel Sandy Bridge ® - Memoria massima condivisa 1760MB con CPU Intel ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 56 - Connettore CPU/Chassis/Alimentazione ventola - 24-pin collettore alimentazione ATX - 4-pin connettore ATX 12V - Connettore audio sul pannello frontale - 2 x Collettore USB 2.0 (supporta 4 porte USB 2.0) ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 57 Certificazioni - FCC, CE, WHQL - Predisposto ErP/EuP (è necessaria l’alimentazione predisposta per il sistema ErP/EuP) (vedi ATTENZIONE 15) * Per ulteriori informazioni, prego visitare il nostro sito internet: http://www.asrock.com ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 58 Windows 7 / Vista / XP. Per Windows OS con CPU 64-bit, non c’è tale limitazione. Si può usare ASRock XFast RAM per ® fare uso della memoria che Windows non può utilizzare. La dimensione massima della memoria condivisa viene stabilita dal ven- ditore del chipset ed e‘...
  • Seite 59 ® . Con questa utilità, si può premere il tasto <F6> durante il POST, oppure il tasto <F2> nel menu BIOS per accedere ad ASRock In- stant Flash. Avviare questo strumento e salvare il nuovo file BIOS nell’unità Flash USB, dischetto (disco floppy) o disco rigido; poi si può aggiornare il BIOS con pochi clic, senza preparare altri dischetti (dischi floppy) o altre complicate utilità...
  • Seite 60 Inoltre accelera di 5 volte la velocità di Adobe Photoshop. Un altro vantaggio di ASRock XFast RAM è che riduce la frequenza d’accesso alle unità SSD o HDD per allungare la loro durata. 13. Se il processore si surriscalda, il sistema si chiude automaticamente. Pri- ma di riavviare il sistema, assicurarsi che la ventolina CPU della scheda madre funzioni correttamente;...
  • Seite 61 CMOS. No- tare che password, data, ore, profilo utente predefinito, 1394 GUID e indirizzo MAC saranno cancellati solo se è rimossa la batteria della CMOS. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com...
  • Seite 62 (LPT1 25 pin) SPD0 SPD1 SPD2 SLCT SPD3 consente di collegare, con (vedi p.2 No. 18) SPD4 BUSY SPD5 ACK# SPD6 comodità, dispositivi di stampa. SPD7 SLIN# PINIT# ERROR# AFD# ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 63 Il LED è acceso quando il sistema è operativo. Il LED continua a lampeggiare quando il sistema è in stato di standby S1. Il LED è spento quando il sistema è in stato di sospensione /ibernazione S3/S4 oppure spento (S5). ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 64 CPU su questa scheda madre, collegarla ai piedini 1-3. Piedini 1-3 collegati Installazione della ventola a 3 piedini Connettore alimentazione ATX Collegare la sorgente d’alimentazione ATX a questo (24-pin ATXPWR1) connettore. (vedi p.2 Nr. 4) ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 65 12 V a questo connettore. (4-pin ATX12V1) (vedi p.2 Nr. 2) Collettore porta COM Questo collettore porta COM è utilizzato per supportare il (9-pin COM1) modulo porta COM. (vedi p.2 Nr. 17) ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 66 Menù principale. Se il Menù principale non appare automaticamente, posizionarsi sul file “ASSETUP.EXE” nel CESTINO del CD di supporto e cliccare due volte per visualizzare i menù. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com...
  • Seite 67: Contenido De La Caja

    1. Introducción Gracias por su compra de ASRock H61M-HVGS / H61M-HVS placa madre, una placa de confianza producida bajo el control de calidad estricto y persistente. La placa madre provee realización excelente con un diseño robusto conforme al com- promiso de calidad y resistencia de ASRock.
  • Seite 68 Ivy Bridge, Pixel ® Shader 4.1, DirectX 10.1 con CPU Intel Sandy Bridge - 1760MB de Memoria máxima compartida con la CPU ® Intel Ivy Bridge. 1759MB de Memoria máxima compartida ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 69 - Conector de ventilador de CPU / chasis / alimentación - 24-pin cabezal de alimentación ATX - 4-pin conector de ATX 12V power - Conector de audio de panel frontal ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 70 - Controladores, utilidades, software de antivirus (versión de prueba), Prueba de CyberLink MediaEspresso 6.5, Conjunto multimedia ASRock MAGIX - OEM Característica - ASRock Extreme Tuning Utility (AXTU) (vea ATENCIÓN 6) Única - ASRock Instant Boot - ASRock Instant Flash (vea ATENCIÓN 7) - ASRock APP Charger (vea ATENCIÓN 8)
  • Seite 71 7 / Vista / XP. Para equipos con Windows OS con CPU de 64-bit, no existe dicha limitación. Puede usar ASRock XFast RAM para utilizar la ® memoria que no puede usar Windows El tamaño de la memoria compartido máximo es definido por el vendedor del chipset y está...
  • Seite 72 Windows 7 / 7 64 bits / Vista / Vista bits y que la versión de su explorador es IE8. Sitio Web de ASRock: http://www.asrock.com/Feature/SmartView/index.asp 10. ASRock XFast USB puede aumentar el rendimiento de los dispositivos de almacenamiento USB.
  • Seite 73 11. ASRock XFast LAN proporciona un acceso a Internet más rápido, que incluye las ventajas que se indican a continuación. Priorización de aplicaciones LAN: Puede configurar la prioridad de las aplicaciones de forma ideal y/o agregar nuevos programas. Menor latencia en los juegos: Después de aumentar la prioridad de los juegos en línea, se puede...
  • Seite 74 Tenga en cuenta que la contraseña, la fecha, la hora, el perfil predeterminado del usuario, el GUID 1394 y la dirección MAC solamente se borrará si la batería CMOS se quita. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com...
  • Seite 75 (LPT1 de 25 terminales) SPD0 SPD1 SPD2 permite conectar cómodamente (vea p.2, N. 18) SLCT SPD3 SPD4 BUSY SPD5 dispositivos de impresión. ACK# SPD6 SPD7 SLIN# PINIT# ERROR# AFD# ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 76 El LED parpadea cuando el sistema se encuentre en estado de suspensión S1. El LED se apaga cuando el sistema se encuentre en estado de suspensión S3/S4 o se apaga (S5). ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com...
  • Seite 77 1-3. Contacto 1-3 conectado Instalación del ventilador de 3 contactos Cabezal de alimentación ATX Conecte la fuente de alimentación ATX a su cabezal. (24-pin ATXPWR1) (vea p.2, N. 4) ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 78 Cabezal del puerto COM Este cabezal del puerto COM se utiliza para admitir un (9-pin COM1) módulo de puerto COM. (vea p.2, N. 17) ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 79 Menú Principal automáticamente si «AUTORUN» está habilitado en su computadora. Si el Menú Principal no aparece automáticamente, localice y doble-pulse en el ar- chivo “ASSETUP.EXE” para iniciar la instalación. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 80 1. Введение Благодарим вас за покупку материнской платы ASRock H61M-HVGS / H61M-HVS надежной материнской платы, изготовленной в соответствии с постоянно предъявляемыми ASRock жесткими требованиями к качеству. Она обеспечивает превосходную производительность и отличается отличной конструкцией, которые отражают приверженность ASRock качеству и долговечности.
  • Seite 81 Ivy Bridge. Макс. объем разделяемой памяти 1759Мб с ® помощью процессора Intel Sandy Bridge. (см. ОСТОРОЖНО, пункт 4) - Двойственное VGA выходное устройство: поддерживает HDMI и D-Sub порты через независимый контроллер дисплея ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 82 - поддержка “Plug and Play” - ACPI 1.1, включение по событиям - поддержка режима настройки без перемычек - поддержка SMBIOS 2.3.1 - центральный IGPU, DRAM, Мультирегулирование Напряжения PCH, CPU PLL, VTT, VCCSA ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 83 Компактдиск - Драйверы, служебные программы, антивирусное программное поддержки обеспечение (пробная версия), Пробная версия программы CyberLink MediaEspresso 6.5, ASRock MAGIX Multimedia Suite - поставщик Уникальная - Средство ASRock Extreme Tuning Utility (AXTU) Особенность (см. ОСТОРОЖНО, пункт 6) - ASRock Instant Boot - ASRock Instant Flash (см.
  • Seite 84 Функция HBR поддерживается только в Windows 7 64-бит / 7 / Vista бит / Vista Служебная программа ASRock Extreme Tuning Utility (AXTU) – это универсальное средство тонкой настройки различных функций системы с удобным и понятным интерфейсом, включающая разделы Hardware Monitor (Наблюдение за оборудованием), Fan Control (Управление...
  • Seite 85 10. Функция ASRock XFast USB увеличивает скорость работы устройств USB. Рост скорости зависит от устройства. 11. ASRock XFast LAN обеспечивает более быстрый доступ к сети Интернет, который даст описанные далее преимущества. Установка приоритетов приложений ЛВС: можно задать оптимальный приоритет для своего...
  • Seite 86 12. ASRock XFast RAM – новая функция, входящая в состав утилиты ASRock Extreme Tuning Utility (AXTU). Благодаря ей, используется область памяти, использование которой не возможно на процессоре с ® 32-битной ОС Windows . ASRock XFast RAM сокращает время загрузки истории посещения веб-сайтов, существенно ускоряя навигацию по сети...
  • Seite 87 затем завершить ее работу. Примите во внимание, что пароль, дата, время, профиль пользователя по умолчанию, идентификатор 1394 GUID и MAC-адрес будут очищены только тогда, когда будет извлечена из своего гнезда батарейка CMOS. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 88 Это интерфейс кабеля порта STB# SPD0 печати, обеспечивающий удобное (25-выводов LPT1) SPD1 SPD2 SLCT SPD3 подключение принтеров. (см. cтр. 2, п.18) SPD4 BUSY SPD5 ACK# SPD6 SPD7 SLIN# PINIT# ERROR# AFD# ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 89 можно настроить. RESET (кнопка сброса): Подключите к этим контактам кнопку сброса на передней панели корпуса. Нажмите кнопку сброса для перезагрузки компьютера, если компьютер «завис» и нормальную перезагрузку выполнить не удается. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 90 вентилятора окажется недоступной. Если вы хотите подключить вентилятор процессора с 3-контактным разъемом к разъему вентилятора процессора на данной материнской плате, для этого следует использовать контакты 1-3. Контакты 1-3 подключены Установка вентилятора с 3-контактным разъемом ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 91 ATX 12 В, чтобы обеспечить достаточную мощность электропитания. В противном случае включение системы будет невозможно. Колодка COM-порта Данная колодка COM-порта позволяет подключить модуль (9-контактный COM1) порта COM. (см. стр. 2, п. 17) ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 92 Если в вашем компьютере включена функция автозапуска (AUTORUN), то на экране автоматически появится главное меню компакт-диска (Main Menu). Если этого не произошло, найдите в папке BIN на компакт-диске поддержки файл ASSETUP.EXE и дважды щелкните на нем, чтобы открыть меню. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 93 1. Introdução Gratos por comprar nossa placa–mãe H61M-HVGS / H61M-HVS um produto con- fiável feito com ASRock um estrito controle de qualidade consistente. Com um excelente desempenho, essa placa é dotada de um projeto robusto que atende a ASRock de compromisso com a qualidade e durabilidade.
  • Seite 94: Especificações

    - Pixel Shader 5.0, DirectX 11 com Intel Ivy Bridge CPU, Pixel ® Shader 4.1, DirectX 10.1 com processadores Intel Sandy Bridge CPU - Memória partilhada máxima 1760MB com CPU Ivy Bridge da ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 95 - Conector do ventilador da CPU/chassis/energia - Conector de força do ATX de 24 pinos - Conector ATX 12 V de 4 pinos - Conector Áudio do painel frontal ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 96 - Controladores, utilitários, software antivírus (Experimentacao Versao), CyberLink MediaEspresso 6.5 versão de demonstração, ASRock MAGIX Multimedia Suite - OEM Funcionalidade - ASRock Extreme Tuning Utility (AXTU) (veja o AVISO 6) Única - ASRock Instant Boot - ASRock Instant Flash (veja o AVISO 7)
  • Seite 97 ® Vista / XP. No caso da CPU de 64 bits do Windows OS, esta limita- ção não existe. Pode usar a função ASRock XFast RAM para utilizar a memória que o Windows ® não pode utilizar. O máximo tamanho de memória compartilhada é definido por vendedor ®...
  • Seite 98 ASRock Instant Flash est un utilitaire de flash du BIOS flash intégré dans la ROM Flash. Cet outil pratique de mise à jour du BIOS vous permet de mettre à jour le BIOS du système sans entrer d’abord dans un système ®...
  • Seite 99 12. ASRock XFast RAM é uma nova função incluída ao utilitário ASRock Ex- treme Tuning Utility (AXTU). Esta função utiliza totalmente o espaço de memória que não pode ser utilizado pela CPU no SO Windows ® OS de 32 bits. A função ASRock XFast RAM diminui o tempo de carregamento de Web sites visitados anteriormente, tornando a navegação na Internet...
  • Seite 100 COMS. Se precisar limpar o CMOS ao concluir a atualização do BIOS, de- verá reiniciar o sistema primeiro e, em seguida, desligá-lo antes de executar a ação de limpeza o CMOS. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 101 SPD1 SPD2 que permite uma ligação (veja a folha 2, No. 18) SLCT SPD3 SPD4 BUSY SPD5 prática para dispositivos de ACK# SPD6 SPD7 impressão. SLIN# PINIT# ERROR# AFD# ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 102 HDLED (LED de actividade do disco rígido): Ligue ao LED de actividade do disco rígido no painel frontal do chassis. O LED ficará acesso quando o disco rígido estiver a ler ou a escrever dados. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com...
  • Seite 103 20 pinos. Para usar a fonte de alimentação de 29 pinos, por favor ligue a sua fonte de alimentação com o Pino 1 e o Pino 13. Instalação da Fonte de alimentação ATX de 20 Pinos ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 104 Conector da porta COM Este conector é usado para suportar um módulo de porta (COM1 de 9 pinos) COM. (veja a folha 2, No. 17) ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 105 CD na leitora de CD-ROM do computador. Automaticamente iniciará o menu princi- pal, casa o AUTORUN esteja ativado. Se o menu principal não aparecer automati- camente, explore o CD e execute o “ASSETUP.EXE” localizado na pasta BIN. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com...
  • Seite 106 önceden haber verilmeksizin değişebilir. Bu belgede değişiklik yapılması durumun -da, güncelleştirilmiş sürüm ayrıca haber verilmeksizin ASRock web sitesinde sunulur. En son VGA kartlarını ve CPU destek listelerini de ASRock web sitesinde bulabilirsiniz. ASRock web sitesi http://www.asrock.com Bu anakartla ilgili teknik desteğe ihtiyacınız olursa, kullandığınız modele özel bilgiler için lütfen web sitemizi ziyaret edin.
  • Seite 107 Sandy Bridge işlemciye sahip DirectX 10.1 ® - Intel Ivy Bridge İşlemci ile Maks. paylaюэlan bellek 1760 MB. ® Intel Sandy Bridge İşlemci ile Maks. paylaюэlan bellek 1759 MB. (bkz. DЭKKAT 4) ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 108 - 2 x USB 2.0 fiş (4 USB 2.0 portu destekler) BIOS Özelliği - 32 Mb AMI BIOS GUI destekli AMI UEFI Geçerli BIOS - “Tak Çalıştır”ı destekler - ACPI 1.1 Uyumlu Uyandırma Olayları - Jumpersız ayarlamayı destekler ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 109 - FCC, CE, WHQL - ErP/EuP Hazır (ErP/EuP hazır güç kaynağı gerekli) (bkz. DİKKAT 15) * Ayrıntılı ürün bilgileri için lütfen web sitemizi ziyaret edin: http://www.asrock.com UYARI Lütfen, ayarı BIOS'da ayarlama, Untied Overclocking Teknolojisi'ni uygulama veya üçüncü taraf aşırı hızlandırma araçlarını kullanma gibi durumlarda aşırı hızlandırmayla ilgili risk olduğunu unutmayın.
  • Seite 110 FAT32/16/12 dosya sistemi kullanması gerektiğini unutmayın. iPhone/iPod/iPad Touch gibi Apple cihazlarınızı şarj etmek için daha hızlı ve daha özgür bir biçimde şarj etmek istiyorsanız, ASRock sizin için ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com...
  • Seite 111 şimdiye kadar olmadığı kadar hızlandırırken önceden ziyaret edilen web sitelerinin yüklenme süresini kısaltır. Ayrıca Adobe Photoshop’ın hızını 5 kat arttırır. ASRock XFast RAM’in başka bir avantajı da, SSD veya HDD’lerinize erişim sıklığını azaltarak kullanım ömürlerini uzatması. 13. CPU aşırı ısınması algılandığında, sistem otomatik olarak kapatılır. Sistemi devam ettirmeden önce, lütfen anakarttaki CPU fanının düzgün çalıştığını...
  • Seite 112 CMOS temizleme işlemini gerçekleştirmeden önce kapatmanız gereklidir. Parola, tarih, saat, kullanıcı varsayılan profili, 1394 GUID ve MAC adresinin yalnızca CMOS pili çıkarıldığında temizleneceğini lütfen aklınızda bulundurunuz. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 113 STB# (25-pinli LPT1) SPD0 SPD1 SPD2 bağlanmasını sağlayan bir (bkz. s.2 No. 18) SLCT SPD3 SPD4 BUSY SPD5 arayüzdür. ACK# SPD6 SPD7 SLIN# PINIT# ERROR# AFD# ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 114 Sistem S3/S4 uyku modunda veya kapalı (S5) iken LED söner. HDLED (Sabit Disk Çalışma LED’i): Kasa üzerindeki sabit disk çalışma LED’ini ön panele bağlayın. Sabit disk veri okurken veya yazarken LED yanar. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 115 20-pinli ATX güç kaynağı bağlarsanız da çalışabilir. 20-pinli ATX güç kaynağını kullanmak için, lütfen güç kaynağınızı Pin 1 ve Pin 13'le birlikte takın. 20-Pinli ATX Güç Kaynağını Takma ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 116 Lütfen bir ATX 12V güç kaynağını bu konektöre (4-pinli ATX12V1) bağlayın. (bkz. s.2 No. 2) Seri port Fişi Bu COM1 fişi bir seri port modülünü destekler. (9-pinli COM1) (bkz. s.2 No. 17) ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 117 Destek CD'sini kullanmaya başlamak için, CD'yi CDROM sürücünüze takın. Bilgisayarınızda "OTOMATİK KULLAN" özelliği etkinleştirilmişse, Ana Menüyü otomatik olarak görüntüler. Ana Menü otomatik olarak görüntülenmezse, menüleri görüntülemek için Destek CD'sinin “BIN” klasöründeki "ASSETUP.EXE" dosyasını bulun ve çift tıklatın. ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 118 ASRock 의 H61M-HVGS / H61M-HVS 메인 보드를 구매하여 주신것에 대하여 감 사 드립니다 . 이 메인보드는 엄격한 품질관리 하에 생산되어진 신뢰성 있는 메인보드 입니다 . 이 제품은 고 품격 디자인과 함께 ASRock 의 우수한 품질과 최고의 안정성 을 자랑하고 있습니다 . 이 빠른 설치 안내서에는 마더보드에 대한 설명과 단계별 설...
  • Seite 119 Ivy Bridge CPU 에서 최대 공유 메모리 1760MB. Intel Sandy Bridge CPU 에서 최대 공유 메모리 1759MB. ( 주의 4 참조 ) - 더블 VGA 수출 : HDMI 와 D-Sub 포트 독립 디스플레이 컨 트롤러를 지원 ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 120 - GUI 지원을 제공하는 AMI UEFI 적합형 BIOS - “플러그 앤 플레이” 지원 - ACPI 1.1 웨이크 - 업 이벤트와의 호환 - 점퍼 프리 지원 - SMBIOS 2.3.1 지원 ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 121 MediaEspresso 6.5 평가판 , ASRock MAGIX Multimedia Suite - OEM 특점및 특성 - ASRock Extreme Tuning Utility (AXTU) ( 주의 6 참조 ) - ASRock Instant Boot - ASRock Instant Flash ( 주의 7 참조 ) - ASRock APP Charger ( 주의 8 참조 ) - ASRock SmartView ( 주의...
  • Seite 122 실제 메모리 크기는 4 GB 이하일 수 있습니다 . 64 비트 CPU 와 Windows ® 의 경우 그런 한계가 없습니다 . ASRock XFast RAM 을 사용하여 Windows 에서 사용할 수 없는 메모리를 이용할 수 있습니다 . 칩세트의 제조원이 정하였거나 그변화를 한제하게되는 최대 공유 메...
  • Seite 123 메모 리 공간을 사용합니다 . ASRock XFast RAM 은 이전에 방문했던 웹사이 트의로딩 시간을 단축하며 웹 서핑을 이전보다 더 빠르게 합니다 . 또한 Adobe Photoshop 속도를 5 배 증가 시킵니다 . ASRock XFast RAM 의 또 다른 장점 은 SSD 또는 HDD 의 액세스 빈도를줄여 수명을 확장 늘입니다 .
  • Seite 124 삭제해야 하는 경우 먼저 시스템을 부팅하고 CMOS 를 종료하고 삭제 작업을 해 야 합니다 . CMOS 배터리를 제거할 경우에만 암호 , 날짜 , 시간 , 사용자 기본 프 로파일 , 1394 GUID, MAC 주소가 삭제됩니다 . ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com...
  • Seite 125 (25 핀 LPT1) SPD2 SLCT SPD3 SPD4 린트 포트 케이블용 인터페이 (2 페이지 , 18 번 항목 참조 ) BUSY SPD5 ACK# SPD6 SPD7 스입니다 . SLIN# PINIT# ERROR# AFD# ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 126 에 있을 때는 LED 가 꺼져 있습니다 . HDLED( 하드 드라이브 동작 LED): 섀시 전면 패널의 하드 드라이브 동작 LED 에 연결합니다 . 하드 드라이 브가 데이터를 읽거나 쓰고 있을 때 LED 가 켜져 있습니다 . ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 127 종래의 20 핀 ATX 전원 공급장치를 사용해도 작동이 가능합니다 . 20 핀 ATX 전원 공급장치를 사용하려면 , Pin 1 과 Pin 13 으로 전원공급장치를 연결하십시오 . 20 핀 ATX 전원 공급장치 설치 ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 128 뉴를 모니터에 디스플레이 시켜 줄 것입니다 . 만일 자동으로 메인 메뉴가 나타나지 않는다면 , 보조 CD 의 디스플레이 메뉴 안에 있는 BIN 폴더 ASSETUP.EXE 파일을 더블 클릭하여 주시기 바랍니다 . (D: \ BIN \ ASSETUP.EXE, D: 는 CD-ROM 드라이브 ) ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 129 ASRock H61M-HVGS / H61M-HVS マザーボード: (Micro ATX フォームファクター : 8.9-in x 6.8-in, 22.6 cm x 17.3 cm) ASRock H61M-HVGS / H61M-HVS クイックインストレーションガイド ASRock H61M-HVGS / H61M-HVS サポート CD 2 x シリアル ATA (SATA) データケーブル(オプション) 1 x I/O パネルシールド ASRockからのお知らせ ...
  • Seite 130 Clear Video HD Technology、 ® ® Intel HD Graphics 2000/3000、Intel Advanced Vector Extensions (AVX) ® - Intel Ivy Bridge CPU を搭載した DirectX 11、Pixel ® Shader 5.0。Intel Sandy Bridge CPU を搭載した ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 131 - CPU/ シャーシ / 電源ファンコネクタ - 24 ピン ATX 電源コネクター - 4 ピン 12V 電源コネクター - フロントパネルオーディオコネクター - USB 2.0 ヘッダー (USB 2.0 用 4 ポートをサポート ) x 2 ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 132 - ASRock Extreme チューニングユーティリティ (AXTU) ( 注意 6 参照 ) - ASRock インスタントブート - ASRock Instant Flash ( 注意 7 参照 ) - ASRock APP ヱャージャー ( 注意 8 を参照 ) - ASRock SmartView ( 注意 9 を参照 ) - ASRock XFast USB ( 注意 10 を参照 ) - ASRock XFast LAN ( 注意...
  • Seite 133 7 64-bit / 7 上でのみ使用できま す。ディープカラーを使用できるのは、ディスプレイが EDID で 12bpc をサ ® ポートしている場合だけです。HBR は Windows 7 64-bit / 7 / Vista 64-bit / Vista で使用できます。 ASRock Extreme Tuning Utility (AXTU) は、分かりやすいインター フェイスでさまざまなシステム機能を微調整するオールインワンツールで、 ハードウェアモニタ、ファンコントロール、オーバークロッキング、OC DNA、ES な どを含んでいます。ハードウェアモニタでは、システムの主要な読み込みを 示します。ファンコントロールでは、調整するファン速度と温度を示します。オー バークロッキングでは、CPU 周波数をオーバークロックして最適のシステムパ フォーマンスを出すことができます。OC DNA では、プロファイルとして OC 設...
  • Seite 134 提供します。LAN アプリケーション優先順位:アプリケーションの理想的な優先 順位を設定し、新しいプログラムを追加することができます。ゲームの低いレ イテンシ : オンラインゲームの優先順位を高く設定した後に、ゲームのレイテン シを下げることができます。トラフィックの成形 :Youtube HD ビデオを視聴し ながらファイルをダウンロードできます。データのリアルタイムの分析 : ステー タスウィンドウがあれば、現在転送しているデータストリームを容易に認識でき ます。 ASRock XFast RAM は、ASRock Extreme Tuning Utility (AXTU) ® を含む新機能です。Windows オペレーティングシステム 32 ビット CPU の 下では使用できないメモリ空間を利用します。 ASRock XFast RAM は、 以前に訪れたウェブサイトの表示にかかる時間を短縮し、これまで以上に迅 速にネットサーフィンを行えるようにします。 また、Adobe Photoshop の処...
  • Seite 135 注 : CLRCMOS1 により、CMOS のデータをクリアできます。システムパラメータをクリアしデフォルト設定にリ セットするには、コンピュータの電源をオフにし、電源装置から電源コードを抜いてください。15 秒待って から、ジャンパキャップを使用して CLRCMOS1 のピン 2 とピン 3 を 5 秒間ショートしてください。ただし、 BIOS 更新の後すぐには CMOS をクリアしないでください。BIOS の更新の終了後直ちに CMOS をクリア する必要がある場合、まずシステムを起動してからシャットダウンし、その後クリア CMOS アクションを実 行する必要があります。パスワード、日付、時刻、ユーザーデフォルトのプロファイルを忘れずにメモして ください。1394 GUID と MAC アドレスは、CMOS バッテリを取り外した場合のみ消去されます。 ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 136 DUMMY USB_PWR プリントポートヘッダ これはプリントポートケーブル用 STB# SPD0 のインターフェイスで、プリンタ (25 ピン LPT1) SPD1 SPD2 SLCT SPD3 デバイスの接続を可能にします。 ページ2, アイテム 18 を参照 SPD4 BUSY SPD5 ACK# SPD6 SPD7 SLIN# PINIT# ERROR# AFD# ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 137 PWRBTN ( 電源スイッチ ): 前面パネルに付いている電源スイッチに接続します。電源スイッチによるシス テム電源オフ方法を設定して変更することも可能です。 RESET ( リセットスイッヱ ): シャーシの前面パネルに付いているリセットスイッチに接続します。コン ピュータがフリーズし、正常な再起動をしない場合は、リセットスイッチを 押してコンピュータを再起動します。 PLED ( システム電源 LED): シャーシの前面パネルに付いている電源ステータスインジケータに接続しま す。LED は、システムが動作しているときに点灯します。LED はシステム が S1 スリープ状態のときに点滅します。システムが S3 または S4 スリープ状 態になるか、電源オフ (S5) になると、LED は消灯します。 ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 138 このマザーボードでは 4 ピン CPU ファン ( クワイエットファン ) がサポートされていますが、 ファン速度コントロール機能がない場合でも、3 ピン CPU ファンは正常に作動します。3 ピン CPU ファンをこのマザーボードの CPU ファンコネクタに接続しようとしている場合、 ピン 1-3 に接続してください。 接続されたピン 1-3 3 ピンファンのインストール ATX パワーコネクタ ATX 電源コネクタを接続します。 (24 ピン ATXPWR1)  ページ2, アイテム 4 を参照 ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 139 このコネクタには CPU に Vcore 電 源を供給できるように、ATX 12V (4 ピン ATX12V1) プラグを備えたサワーサプライを ページ2, アイテム 2 を参照 接続する必要があることに注意し てください。接続に問題があると、電源 は正しく供給されません。 シリアルポートヘッダ この COM1 ヘッダは、シリアルポートモ ジュールをサポートします。 (9 ピン COM1) ページ2, アイテム 17 を参照 ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 140 / XP / XP 64-bit といった様々なマイクロソフト ウインドウズ オペレーティングシ ステムをサポートします。マザーボードに付属しているサポート CD はマザーボードの特徴 を有効にするために必要なドライバやユーティリティを含んでいます。サポート CD を使用 するには、CDROM ドライブに CD を挿入してください。AUTORUN 機能が有効な場合、自 動的にメインメニュウが立ち上がります。AUTORUN 機能が無効な場合、サポート CD 内の BIN フォルダにある ASSETUP.EXE をダブルクリックすることにより、メインメニュウが立ち 上がります。 ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 141 1. 主板簡介 謝謝你采用了華擎 H61M-HVGS / H61M-HVS 主板 , 本主板由華擎嚴格制造 , 質量可靠 , 穩定性好 , 能夠獲得卓越的性能。本安裝指南介紹了安裝主板的步驟。更加詳細的主 板信息可參看驅動光盤的用戶手冊。 由于主板規格和 BIOS 軟件將不斷升級 , 本手冊之相關內容變更恕不另 行通知。請留意華擎网站上公布的升級版本。你也可以在華擎網站找 到最新的顯卡和 CPU 支持表。 華擎网址:http://www.asrock.com 如果您需要與此主板有關的技術支持 , 請參觀我們的網站以了解您使用機 種的規格信息。 www.asrock.com/support/index.asp 1.1 包裝盒內物品 華擎 H61M-HVGS / H61M-HVS 主板 (Micro ATX 規格 : 8.9 英吋 X 6.8 英吋 , 22.6 厘米 X 17.3 厘米 ) 華擎...
  • Seite 142 ® - 通過 Intel Ivy Bridge CPU 支持最大共享內存 1760MB。通 ® 過 Intel Sandy Bridge CPU 支持最大共享內存 1759MB。 (見警告 4) - 雙 VGA 輸出 : 通過獨立顯示控制器提供 HDMI 和 D-Sub 接口 ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 143 - ACPI 1.1 電源管理 - 支持喚醒功能 - 支持 jumperfree 免跳線模式 - IGPU、DRAM、PCH、CPU PLL、VTT、VCCSA 電壓多功能調節器 支持光盤 - 驅動程序 , 工具軟件 , 殺毒軟件(測試版本 ),CyberLink MediaEspresso 6.5 試用版 , 華擎 MAGIX 多媒体套件 - OEM ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 144 獨家功能 - ASRock Extreme Tuning Utility (AXTU)(詳見警告 6) - 華擎即時開機功能 - 華擎 Instant Flash(見警告 7) - 華擎 APP Charger(見警告 8) - 華擎 SmartView(見警告 9) - 華擎 XFast USB(見警告 10) - 華擎 XFast LAN(見警告 11) - 華擎 XFast RAM(見警告 12) - Hybrid Booster( 安心超頻技術 ): - ASRock U-COP(見警告...
  • Seite 145 10、 華擎 XFast USB 可以提升 USB 存儲設備性能。性能可能因設備特性不同而 存在差异。 11、 華擎 XFast LAN 可提供更快的网絡訪問,包括以下諸多好處。网絡應用程 序优先級:您可以設置理想的應用程序优先級,并可以添加新程序。游戲 更少延遲:將在線游戰設置為較高的优先級,可降低游戰中的延遲。流量 定形:您可以在觀看 Youtube 高清視頻的同時進行文件下載。實時分析您 的數据:通過狀態窗口,您可以清楚地看到目前正在傳輸的是哪個數据 流。 12、華擎 XFast RAM 是 ASRock Extreme Tuning Utility (AXTU) 中加入的一項 ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 146 立即清除 C M O S。如果需要在更新 B I O S 后立即清除 C M O S,必須在執行 C M O S 清除操作之前,先啟動然后關閉系統。請注意,只有取出 C M O S 電池,密碼、 日期、時間、用戶默認配置文件、1394 GUID 和 MAC 地址才會被清除。 ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 147 ( 見第 2 頁第 18 項 ) ACK# SPD6 SPD7 SLIN# PINIT# ERROR# AFD# 前置音頻面板接頭 可以方便連接音頻設備。 PRESENCE# (9 針 HD_AUDIO1) MIC_RET OUT_RET ( 見第 2 頁第 19 項 ) OUT2_L J_SENSE OUT2_R MIC2_R MIC2_L ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 148 機模式或關機 (S5) 模式時 , 此指示燈熄滅。 HD LED( 硬盤活動指示燈 ): 連接機箱前面板的硬盤動作指示燈。當硬盤正在讀取或寫入數據時 , 此指示燈亮起。 前面板設計因機箱不同而有差異。前面板模塊一般由電源開關、 重啟開關、電源指示燈、硬盤動作指示燈、喇叭等構成。將您的機 箱前面板連接到此排針時 , 請確認連接線與針腳上的說明相對應。 機箱喇叭接頭 請將機箱喇叭連接到這個接 頭。 (4 針 SPEAKER1) ( 見第 2 頁第 13 項 ) ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 149 請將一個 ATX 12V 電源供應 器接到這個接頭。 (4 針 ATX12V1) ( 見第 2 頁第 2 項 ) 串行接口連接器 這個 COM1 端口支持一個串行 接口的外設。 (9 針 COM1) ( 見第 2 頁第 17 項 ) ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 150 進行常規檢驗。如果你需要在開機自檢 ( P O S T ) 之后進入 B I O S 設置程序,請按下 <Ctrl>+<Alt>+<Delete> 鍵重新啟動電腦,或者按下系統面板上的重啟按鈕。有關 BIOS 設置的詳細信息,請查閱隨機支持光盤裡的用戶手冊 (PDF 文件 )。 3. 支持光盤信息 ® ® 本主板支持各種微軟視窗操作系統:Microsoft Windows 7/7 64 位元 /Vista Vista 64 位元 /XP/XP 64 位元。主板隨機支持光盤包含各種有助于提高主板效能的 必要驅動和實用程序。請將隨機支持光盤放入光驅裡,如果電腦的“自動運行”功能 已啟用,屏幕將會自動顯示主菜單。如果主菜單不能自動顯示,請查找支持光盤內 BIN 文件夾下的“ASSETUP.EXE”,并雙擊它,即可調出主菜單。 ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 151 鉛 (Pb) 鎘 (Cd) 汞 (Hg) 六价鉻 (Cr(VI)) 多溴聯苯 (PBB) 多溴二苯醚 (PBDE) 印刷電路板 及電子組件 外部信號連 接頭及線材 O: 表示該有毒有害物質在該部件所有均質材料中的含量均在 SJ/T 11363-2006 標準規定 的限量要求以下。 X: 表示該有毒有害物質至少在該部件的某一均質材料中的含量超出 SJ/T 11363-2006 標準 規定的限量要求,然該部件仍符合歐盟指令 2002/95/EC 的規範。 備註 : 此產品所標示之環保使用年限,系指在一般正常使用狀況下。 ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 152 1. 主機板簡介 謝謝你採用了華擎 H61M-HVGS / H61M-HVS 主機板 , 本主機板由華擎嚴格製造 , 品質 可靠 , 穩定性好 , 能夠獲得卓越的性能。此快速安裝指南包括了主機板介紹和分步驟 安裝指導。您可以查看支持光碟裡的使用手冊了解更詳細的資料。 由於主機板規格和 BIOS 軟體將不斷更新 , 本手冊之相關內容變更恕不另 行通知。請留意華擎網站上公布的更新版本。你也可以在華擎網站找到最 新的顯示卡和 CPU 支援列表。 華擎網址:http://www.asrock.com 如果您需要與此主機板有關的技術支援 , 請參觀我們的網站以了解您使用 機種的規格訊息。 www.asrock.com/support/index.asp 1.1 包裝盒內物品 華擎 H61M-HVGS / H61M-HVS 主機板 (Micro ATX 規格 : 8.9 英吋 x 6.8 英吋 , 22.6 公分 x 17.3 公分 ) 華擎...
  • Seite 153 Ivy Bridge CPU 支援 Pixel Shader 5.0、DirectX 11 ® 技術。Intel Sandy Bridge CPU 支援 Pixel Shader 4.1、 DirectX 10.1 技術。 ® - 透過 Intel Ivy Bridge CPU 支援最大共享記憶體 1760MB。 ® 透過 Intel Sandy Bridge CPU 支援最大共享記憶體 ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 154 - 32Mb AMI BIOS - AMI UEFI Legal BIOS ( 支援 GUI) - 支援即插即用(Plug and Play,PnP) - ACPI 1.1 電源管理 - 支援喚醒功能 - 支援 jumperfree 免跳線模式 - IGPU、DRAM、PCH、CPU PLL、VTT、VCCSA 電壓多功能調節 ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 155 支援光碟 - 驅動程式 , 工具軟體 , 防毒軟體(試用版本 ),CyberLink MediaEspresso 6.5 試用版 , 華擎 MAGIX 多媒體套餐 - OEM 獨家功能 - ASRock Extreme Tuning Utility (AXTU)(詳見警告 6) - 華擎即時開機功能 - 華擎 Instant Flash(見警告 7) - 華擎 APP Charger(見警告 8) - 華擎 SmartView(見警告 9)...
  • Seite 156 EDID 中支援 12bpc 時 ,Deep Color 模式才會被開啟。只有 Windows 7 64 位元 /7/Vista 64 位元 /Vista 支援 HBR。 6、 ASRock Extreme Tuning Utility (AXTU) 是一款多合一的工具,易於操 作的使用者介面便於微調不同的系統功能(例如:Hardware Monitor、 Fan Control、Overclocking、OC DNA 及 IES)。Hardware Monitor 可顯 示系統的主要讀數;Fan Control 可顯示並可供您調整風扇速度及溫度; Overclocking 可供您進行 CPU 超頻以獲得最佳系統效能。透過 OC DNA,...
  • Seite 157 在觀看 Youtube 高解析影片的同時還進行文件下載。及時分析您的數據:透 過狀態窗口,您可以清楚地看到目前正在傳輸的是哪個數據流。 12、 華擎 XFast RAM 是 ASRock Extreme Tuning Utility (AXTU) 中加入的一項 ® 新功能。它能充分利用 Windows 操作系統 32-bit CPU 無法使用的記憶體空 間。華擎 XFast RAM 可縮短之前訪問過的網站的讀取時間,從而加快網路瀏 覽速度。此外,它還能提升 Adobe Photoshop 執行的速度高達五倍之多。華 擎 XFast RAM 的另一項優勢是它能減少使用 SSD 或 HDD 的頻率,從而延長它 門的使用壽命。 13、 當檢測到 C P U 過熱問題時,系統會自動關機。在您重新啟動系統之前,請...
  • Seite 158 這是一個連接印表機的接 STB# SPD0 SPD1 口,方便您連接印表機設 (25 針 LPT1) SPD2 SLCT SPD3 SPD4 備。 BUSY ( 見第 2 頁第 18 項 ) SPD5 ACK# SPD6 SPD7 SLIN# PINIT# ERROR# AFD# ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 159 PLED( 系統電源指示燈 ): 連接機箱前面板的電源狀態指示燈。當系統運行時 , 此指示燈亮起。 當系統處於 S1 待命模式時 , 此指示燈保持閃爍。當系統處於 S3/S4 待 命模式或關機 (S5) 模式時 , 此指示燈熄滅。 HD LED( 硬碟活動指示燈 ): 連接機箱前面板的硬碟動作指示燈。當硬碟正在讀取或寫入數據時 , 此指示燈亮起。 前面板設計因機箱不同而有差異。前面板模組一般由電源開關、 重開開關、電源指示燈、硬碟活動指示燈、喇叭等構成。將您的機 箱前面板連接到此接頭時 , 請確認連接線與針腳上的說明相對應。 ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 160 著 Pin 1 和 Pin 13 插上電源接頭。 20-Pin ATX 電源安裝說明 ATX 12V 電源接口 請注意,必需將帶有 ATX 12V 插頭的電源供應器連接到這個 (4 針 ATX12V1) 插座,這樣就可以提供充足的 ( 見第 2 頁第 2 項 ) 電力。如果不這樣做,就會導 致供電故障。 ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 161 裡的使用手冊 (PDF 文件 )。 3. 支援光碟訊息 ® ® ® 本主板支援各種微軟 Windows 操作系統:Microsoft Windows 7/7 64 位元 / Vista /Vista 64 位元 /XP/XP 64 位元。主板附帶的支援光碟包含各種有助於提高主 板效能的必要驅動和實用程式。請將隨機支援光碟放入光碟機裡,如果系統的“自動 運行”功能已啟用,銀幕將會自動顯示主菜單。如果主菜單不能自動顯示,請查閱支 援光碟內 BIN 文件夾下的 ASSETUP.EXE 文件並雙點它,即可調出主菜單。 ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...
  • Seite 162 4. Start Windows installation. ® 5. If you install Windows 7 64-bit OS, OS will be formatted by GPT (GUID Partition ® Table). Please install the hotfix file from Microsoft http://support.microsoft.com/kb/979903 ASRock H61M-HVGS / H61M-HVS Motherboard Downloaded from www.Manualslib.com manuals search engine...

Diese Anleitung auch für:

H61m-hvs

Inhaltsverzeichnis
