3.2 IUPS-401-B1/-B4/-BA/-B9/-110-B7

To optimize the service life of the battery install the IUPS into the computer at a
location with preferably low temperature.
Disconnect mains before starting the installation!
1. Disconnect mains
3. Connect 5-pole control cable at the IUPS
5. Connect the IUPS mains cable with the power
supply of the computer
28
User Manual IUPS-401-Series
2. Install slot bracket with 5-pole control cable
4. Connect mains cable of the IUPS and the special
IUPS cable
6. Connect mains plug with the IUPS mains cable
