I/O Panel
No. Description
1
2
3
4
5
6
7
8
Downloaded from www.Manualslib.com
1
15 14
USB 2.0 Ports (USB01)
D-Sub Port
DisplayPort 1.2*
LAN RJ-45 Port**
Central / Bass (Orange)
Rear Speaker (Black)
Line In (Light Blue)
Front Speaker (Lime)***
manuals search engine
2 3
13 12
No. Description
9 Microphone (Pink)
10 Optical SPDIF Out Port
11 USB 3.0 Ports (USB3_4_5)
12 HDMI Port*
13 DVI-D Port
14 USB 3.0 Ports (USB3_0_1)
15 PS/2 Mouse/Keyboard Port
QC5000-ITX/PH
